Sonance VX 86R - 2 Way In Wall/ In Ceiling Speaker

Sonance VX86R built-in speakers

The Visual Experience series built-in speakers set new standards in installation efficiency, sound quality and design flexibility. Thanks to a selection of round, square and rectangular covers and various sizes, the speakers can be seamlessly integrated into any architectural concept. This variety enables precise coordination with the shapes of the installed lighting elements. Different power levels ensure excellent audio quality that meets even the most demanding standards and ensures impressive sound reproduction throughout the living area. All models in the VXQ series are also optimized for use in damp rooms.

FLEX FRAME MOUNTING SYSTEM

The Flex Frame mounting system combines an installation frame with a loudspeaker module to ensure maximum flexibility during the installation process. Choose between the proven method, which is similar to the VP series, or a two-step installation, which allows for even easier handling. Models of the VX and VXQ series with performance levels 0 and 8 are assembled in one step.

DESIGN AND OPTICS

The Visual Experience series impresses with an impressive variety of designs. Different grille sizes, grille types and form factors open up almost unlimited customization options to harmoniously integrate the speaker design into ceiling images and room furnishings.

The standard grille of the VX series is supplied in signal white (RAL9003) and is particularly durable thanks to a UV stabilizer. The slim plastic edge of the VP series has been adopted and reduced to 3 mm, which means that the proven properties such as seamless transitions and shadow-free integration are retained. For even more design freedom, trimless grilles without a plastic edge are available separately, also in signal white (RAL9003) and with a UV stabilizer.

Preparations for flush installations are in the final development phase. The mounting plates provided for this purpose ensure perfect integration and are based on the popular installation solutions of the VP series, which will be available for all models in the future.

INDIVIDUALIZATION (CUSTOM)

Sonance offers extensive options for customizing the speaker covers, which can be designed according to individual customer requirements. The cover grilles can be painted in any desired color or laser printed with specific motifs or textures. This means that the speakers in the Visual Experience series fit seamlessly and unobtrusively into any room.

For example, you want to install speakers in a concrete-look wall? No problem! Choose between a uniform gray paint finish or an authentic laser print with a concrete texture to achieve the aesthetic you want.

General Specifications

• Manufacturer : Sonance
• Design : Square, Round

performance and sound quality

• Operating power : 150 watts
• Efficiency : 91 dB (2.83 V/1 m)
• Frequency response : 34 Hz – 20 kHz (+/- 3 dB)
• Impedance : 8 Ohm nominal

Dimensions

• Diameter : 293 mm
• Installation diameter : 257 mm
• Installation depth : 140 mm, 166 mm

installation depth classification

• Compatible with installation depths up to : 150 mm, 200 mm
