Dali Phantom CI AMP-2500 DSP Amplifier
€2,199.00
per Piece incl. VAT / incl. Shipping
Available in 7 days, delivery time 1-3 days
GermanyWe ship your goods quickly and safely with DHL. After shipping you will receive a tracking number for package tracking.
DALI
PHANTOM CI AMP-2500 DSP AMPLIFIER
The versatile PHANTOM CI AMP-2500 DSP amplifier completes the Dali portfolio for individual installations. The versatile and powerful AMP-2500 DSP features onboard digital signal processing and model-specific presets to get the best possible audio experience out of any DALI CI audio installation.
With 2 x 500 watts of engineered Class D amplification, the CI AMP-2500 DSP offers effortless performance, ultra-high efficiency, and ultra-low distortion. This fan-cooled, rack-mountable powerhouse of an amp can also be bridged to a 1,000-watt mono amp. With this performance, the CI AMP-2500 DSP is the perfect power source for the PHANTOM S and M series and up to four PHANTOM IW SUB S-100 wall subwoofers.
The PHANTOM CI AMP-2500 DSP features a powerful suite of built-in DSP tools, including parametric equalizers, audio limiters and compressors, routing matrix, input/output settings, speaker delay and speaker presets, all about The web-based PHANTOM AMP configurator can be controlled from any Wi-Fi enabled computer, tablet or smartphone.
The multi-purpose amplifier is primarily intended for powerful home cinema installations based on PHANTOM M and S series CI loudspeakers and in-wall subwoofers, but can also power wall and ceiling speakers in a multi-room installation, so that it is also suitable for bars, restaurants, cafes and gyms.
Technical data
- Frequency Response: 12Hz - 20kHz (+/- 0.5dB)
- Inputs:
- 4x analog (RCA)
- 4x analog (Phoenix)
- 1x digital (cinch)
- Input impedance: 10 kΩ
- Outputs:
- 2x Lo-Z (4 – 16 O)
- 2x Hi-Z (70V / 100V)
- 1x digital (cinch)
- Output power:
- 2x 500 W (2 O / 4 O)
- 2x 250W (8O)
- 1x 1000W (bridge mode: 4 O / 8 O / 70V / 100V)
- Output voltage: 65 Vp / 130 Vpp or 130 Vp / 260 Vpp (bridge mode)
- Signal to noise ratio: > 108 dB
- Power Consumption: 350W; < 0.5W (standby)
measures and weight
- 2U rack dimension
- Dimensions: 88x440x332mm
- Weight: 5.9kg
Accessories (included in scope of delivery):
- 2x Balanced dual channel input connector
- 1x Balanced dual channel output connector
- 1x GPIO female connector
- 1x power cord
- 4x rubber feet
- 2x rack mounting brackets (installed)
| Color: | black |
|---|---|
| Condition: | new item |
| Device depth mm: | 332 |
| Device height mm: | 88 |
| Device width mm: | 440 |
| Product type: | amplifier |
Manufacturer
DALI A/S
Dali Allé 1
9610 Noerager
Denmark
www.dali-speakers.com
support@dali.dk
Safety Information
Product-specific safety instructions can be found in the operating manual.
