Nagaoka MP-100 H Cartridge with Head Shell
€169.00
per Piece incl. VAT / incl. Shipping
Available, delivery time: 1-3 days
GermanyWe ship your goods quickly and safely with DHL. After shipping you will receive a tracking number for package tracking.
The MP-100 cartridge with its round diamond is especially suitable for older vinyl records. Even scratches and dirt do not impair the pleasant, neutral sound image that this system makes possible. The MP-100 is the cheapest pickup in the MP series.
Technical Specifications
- Principle: MP - High Output /for the MM input)
- Weight: 6,5 g
- Height 18mm
- Needle cut: Round 0.6mim
- Needle carrier: aluminium
- Frequency response: 20 - 20,000 Hz
- Output voltage (1kHz, 5cm/sec): 5.0 mV
- Channel separation (1kHz): > 22 dB
- Channel balance (1kHz): < 2.0 dB
- Needle compliance: 19 µm/mN
- Recommended contact force: 21 mN (18-23 mN)
- Recommended termination resistor: 47 kOhm
- Recommended termination capacity: 150 - 200 pF
- Replacement needle: JN-P100
| Cartridge type: | with head shell |
|---|---|
| Condition: | new item |
| Product type: | Pickup MI |
| Promotion: | no |
| Series: | MP |
Manufacturer
Nagaoka Trading Co.
Ltd.
4-3-2
Sendagaya
Shihuya-ku
Tokyo
151-0051 Japan
EU Representative
Auditorium GmbH
Feidikstraße 93
59065 Hamm
Germany
shop@auditorium.de
Safety Information
Product-specific safety instructions can be found in the operating manual.
