T+A MP 3100 HV - SACD Drive and DSP/PCM DAC

€16,500.00

per Piece incl. VAT / incl. Shipping

Color
Information
2% Cash Discount
We grant a cash discount when paying by advance transfer.
No longer available

Hamm
Stock 0

Hamburg
Stock 0

Münster
Stock 0
Premium Installation
Premium Installation

  1. After placing your order, your Account Manager will contact you to schedule delivery and installation.
  2. We deliver your new devices in Germany and Austria personally to the place of installation - no courier, no forwarding agency.
  3. The Auditorium Team installs your new devices professionally and connects them to existing components.
Learn more
Product number: 279363
Product­information
Product information MP 3100 HV - SACD Drive and DSP/PCM DAC
Productnumber

279363

The MP 3100 HV is the ultimate multi-source SACD player, characterized by its comprehensive media support and superior sound quality. Based on the proven concept of the MP 3000 HV, the MP 3100 HV has been enhanced with the latest technology to process both PCM data and DSD bitstreams in the highest quality. Thanks to a newly developed SACD drive, the player offers superior playback of CD (PCM 44.1 kSps) and SACD (DSD 64 2.8 MHz) discs, which also benefits the other digital sources.

The MP 3100 HV features the state-of-the-art double differential quadruple converter for PCM data as well as the unique True 1-bit DSD converter, which processes DSD data natively. This enables playback of DSD 512 in the best quality via the USB input of the Digital Connecting Board. As a high-res streaming client, it supports various music services, Internet radio and connection to home networks via LAN and WLAN. An integrated FM, FM-HD and DAB+ tuner as well as a high-quality Bluetooth module round off the range. It is conveniently controlled via the F 3100 infrared remote control or the T+A MusicNavigator app.

Technical data

  • Drive : Precision linear drive with double laser system (SACD: 650 nm, CD: 785 nm)
  • Formats : SACD Stereo, CD, CD-R, CD-RW, SACD/CD Text
  • Frequency response / dynamics :
    • SACD: 2 Hz - 44 kHz / 110 dB
    • CD: 2 Hz - 20 kHz / 100 dB
  • Streaming Clients :
    • Formats / Standards : MP3, WMA, AAC, OGG Vorbis, FLAC, WAV, AIFF, ALAC / UPnP AV
    • Data rate : PCM 32...192 kHz, 16/24 bit; MP3 up to 320 kBit, constant and variable data rate
    • Services : Tidal, Qobuz, Deezer, Roon Ready (subscription required)
    • Features : Gapless Playback, T+A MusicNavigator App for iOS and Android
    • Network connection : LAN: Fast Ethernet 10/100 Base-T, WLAN: 802.11 b/g/n
  • Tuners :
    • Internet Radio : Airable Internet Radio Service (> 11000 stations worldwide)
    • FM, FM-HD : 87.5 - 108 MHz; sensitivity 1 µV; S/N > 65 dBA
    • DAB, DAB+ : 168 - 240 MHz (Band III); Sensitivity 2.0 µV, S/N > 96 dBA
    • Features : RDS/RDBS, station name, program type, radio text, time
  • Bluetooth : A2DP (Audio), AVRCP 1.4 (Control) / aptX®, MP3, SBC
  • Connections :
    • Analog : Co-Axial (RCA) | Balanced (XLR), 2.5 Vrms / 50 Ohm | 5.0 Vrms / 50 ohms
    • Digital : 1 x coax, IEC 60958 S/P-DIF (LPCM)
    • Digital inputs :
      • 1x AES-EBU 32...192 kHz / 16-24 bit
      • 5x S/P-DIF: 1x standard coax, 2 high-quality BNC 32...192 kHz / 16-24 bit, 2 optical TOS-Link 32...96 kHz / 16-24 bit
      • 1x USB: Device mode with max. 384 kSps (PCM) and DSD512*, asynchronous data transfer
      • 2x USB master mode for USB mass storage (stick or HDD)
  • D/A converter :
    • PCM : Double differential quadruple converter with 4 D/A converters per channel, 32-bit Sigma Delta, 352.8 kSps/384 kSps
    • DSD : T+A True 1Bit DSD D/A converter, up to DSD 512 (22 MHz)
    • Upsampling (PCM) : 4 selectable oversampling algorithms (FIR short, FIR long, Bezier/IIR, Bezier)
    • Analogue filter : Phase-linear 3rd order Bessel filter with 60 or 120 kHz cutoff frequency
    • Frequency response :
      • PCM 44.1 kSps: 2 Hz - 20 kHz
      • PCM 48 kSps: 2 Hz - 22 kHz / DSD 64: 2 Hz - 44 kHz
      • PCM 96 kSps: 2 Hz - 40 kHz / DSD 128: 2 Hz - 60 kHz
      • PCM 192 kSps: 2 Hz - 80 kHz / DSD 256: 2 Hz - 80 kHz
      • PCM 384 kSps: 2 Hz - 100 kHz / DSD 512: 2 Hz - 100 kHz
  • Distortion factor : < 0.001 %
  • Signal-to-noise ratio : > 116 dB
  • Channel separation : > 110 dB
  • Mains connection : 2x 110-120 V or 220-240 V, 50-60 Hz, 2x 40 W
  • Standby : < 0.5W
  • Dimensions (H x W x D) / Weight : 17 x 46 x 46 cm / 26 kg
  • Remote control : F 3100, infrared remote control, T+A MusicNavigator app
  • Accessories : 2x power cable, WLAN antenna, BNC/Cinch adapter
  • Optional accessories : Power Three HD (Carbon), Power Bar, Audio Quad (Carbon), HV-Individual version (individual desired colors)


Color: silver
Condition: new item
Device depth mm: 460
Device height mm: 170
Device width mm: 460
Product type: drive
Product number 279363

The MP 3100 HV is the ultimate multi-source SACD player, characterized by its comprehensive media support and superior sound quality. Based on the proven concept of the MP 3000 HV, the MP 3100 HV has been enhanced with the latest technology to process both PCM data and DSD bitstreams in the highest quality. Thanks to a newly developed SACD drive, the player offers superior playback of CD (PCM 44.1 kSps) and SACD (DSD 64 2.8 MHz) discs, which also benefits the other digital sources.

The MP 3100 HV features the state-of-the-art double differential quadruple converter for PCM data as well as the unique True 1-bit DSD converter, which processes DSD data natively. This enables playback of DSD 512 in the best quality via the USB input of the Digital Connecting Board. As a high-res streaming client, it supports various music services, Internet radio and connection to home networks via LAN and WLAN. An integrated FM, FM-HD and DAB+ tuner as well as a high-quality Bluetooth module round off the range. It is conveniently controlled via the F 3100 infrared remote control or the T+A MusicNavigator app.

Technical data

  • Drive : Precision linear drive with double laser system (SACD: 650 nm, CD: 785 nm)
  • Formats : SACD Stereo, CD, CD-R, CD-RW, SACD/CD Text
  • Frequency response / dynamics :
    • SACD: 2 Hz - 44 kHz / 110 dB
    • CD: 2 Hz - 20 kHz / 100 dB
  • Streaming Clients :
    • Formats / Standards : MP3, WMA, AAC, OGG Vorbis, FLAC, WAV, AIFF, ALAC / UPnP AV
    • Data rate : PCM 32...192 kHz, 16/24 bit; MP3 up to 320 kBit, constant and variable data rate
    • Services : Tidal, Qobuz, Deezer, Roon Ready (subscription required)
    • Features : Gapless Playback, T+A MusicNavigator App for iOS and Android
    • Network connection : LAN: Fast Ethernet 10/100 Base-T, WLAN: 802.11 b/g/n
  • Tuners :
    • Internet Radio : Airable Internet Radio Service (> 11000 stations worldwide)
    • FM, FM-HD : 87.5 - 108 MHz; sensitivity 1 µV; S/N > 65 dBA
    • DAB, DAB+ : 168 - 240 MHz (Band III); Sensitivity 2.0 µV, S/N > 96 dBA
    • Features : RDS/RDBS, station name, program type, radio text, time
  • Bluetooth : A2DP (Audio), AVRCP 1.4 (Control) / aptX®, MP3, SBC
  • Connections :
    • Analog : Co-Axial (RCA) | Balanced (XLR), 2.5 Vrms / 50 Ohm | 5.0 Vrms / 50 ohms
    • Digital : 1 x coax, IEC 60958 S/P-DIF (LPCM)
    • Digital inputs :
      • 1x AES-EBU 32...192 kHz / 16-24 bit
      • 5x S/P-DIF: 1x standard coax, 2 high-quality BNC 32...192 kHz / 16-24 bit, 2 optical TOS-Link 32...96 kHz / 16-24 bit
      • 1x USB: Device mode with max. 384 kSps (PCM) and DSD512*, asynchronous data transfer
      • 2x USB master mode for USB mass storage (stick or HDD)
  • D/A converter :
    • PCM : Double differential quadruple converter with 4 D/A converters per channel, 32-bit Sigma Delta, 352.8 kSps/384 kSps
    • DSD : T+A True 1Bit DSD D/A converter, up to DSD 512 (22 MHz)
    • Upsampling (PCM) : 4 selectable oversampling algorithms (FIR short, FIR long, Bezier/IIR, Bezier)
    • Analogue filter : Phase-linear 3rd order Bessel filter with 60 or 120 kHz cutoff frequency
    • Frequency response :
      • PCM 44.1 kSps: 2 Hz - 20 kHz
      • PCM 48 kSps: 2 Hz - 22 kHz / DSD 64: 2 Hz - 44 kHz
      • PCM 96 kSps: 2 Hz - 40 kHz / DSD 128: 2 Hz - 60 kHz
      • PCM 192 kSps: 2 Hz - 80 kHz / DSD 256: 2 Hz - 80 kHz
      • PCM 384 kSps: 2 Hz - 100 kHz / DSD 512: 2 Hz - 100 kHz
  • Distortion factor : < 0.001 %
  • Signal-to-noise ratio : > 116 dB
  • Channel separation : > 110 dB
  • Mains connection : 2x 110-120 V or 220-240 V, 50-60 Hz, 2x 40 W
  • Standby : < 0.5W
  • Dimensions (H x W x D) / Weight : 17 x 46 x 46 cm / 26 kg
  • Remote control : F 3100, infrared remote control, T+A MusicNavigator app
  • Accessories : 2x power cable, WLAN antenna, BNC/Cinch adapter
  • Optional accessories : Power Three HD (Carbon), Power Bar, Audio Quad (Carbon), HV-Individual version (individual desired colors)
Read more Close

Mains voltage

If your mains voltage is not 230 volts, please specify the desired voltage for the device in the comment field of your order. We will have the device configured accordingly by the manufacturer.

Color: silver
Condition: new item
Device depth mm: 460
Device height mm: 170
Device width mm: 460
Product type: drive

Manufacturer

T+A elektroakustik GmbH & Co. KG
Planckstraße 9–11
32052 Herford
Germany
