Dynaudio Contour 20i Compact loudspeaker
€5,000.00
per Pair (Unit Price: 2.500,00 €) incl. VAT / incl. Shipping
Available in 7 days, delivery time 1-3 days
GermanyWe ship your goods quickly and safely with DHL. After shipping you will receive a tracking number for package tracking.
Contour 20i
Dedicated to every detail
Compact? Yes. Compact sounding? no
Hear the difference: the new Contour 20i will literally blow you away.
The new Contour 20i was designed to outperform every other compact Contour model Dynaudio has ever created. And it succeeded.
The new Esotar 2i tweeter is like a turbocharged version of the popular Esotar2. It now features a larger absorption chamber for more effective cushioning and the inventive Hexis Dome seen on the Confidence, Core and other models. Together they flatten the frequency response and reduce unwanted resonances for even clearer, smoother highs.
The woofer has also been optimized. It's still made from Dynaudio's proprietary Magnesium Silicate Polymer (MSP) material, of course it's still powered by a lightweight aluminum voice coil and it still uses a vented dual ferrite magnet system - but behind the distinctive black diaphragm hides a brand new centering spider. This is made from aramid fibers and retains the ingenious structural qualities of yesteryear (the ribs are of different widths to allow for even finer control over cone deflection). You'd be surprised at the sonic difference such a small change can make...
And because these driver changes offer an inherently flat frequency response, Dynaudio has been able to simplify the crossover as well. It's a beauty thing, isn't it? No additional impedance correction circuitry is required - which means an even more direct signal path. And a cleaner sound.
Doing a contour without the signature baffle would be like a car without wheels. Unthinkable. But there's always room for improvement - and our designers love to stretch their legs. This baffle is made of aluminum and is embedded in the housing. The rounding of the baffle is continued in the driver basket - this not only looks good but also reduces unwanted high frequency diffraction effects for clearer highs and provides a solid base for the drivers to work. A solid foundation means improved high volume performance even at low frequencies (although your neighbors might not thank us for that).
Even the inner cushioning is brand new - based on the experience of the Evoke and Confidence series.
voice coil
Large diameter, long throw voice coil
New crossover
Extensive optimizations to the Contour 2016 have resulted in a simpler, more puristic and simply better crossover.
New centering spider
New centering spider with asymmetrical folding for better vibration behavior - and now made of aramid fibers for even better sound quality.
The new Esotar 2i tweeter
Equipped with a larger rear absorption chamber and the ingenious Hexis Dome inside, which further minimizes resonances and leads to even lower distortion values with a smoother frequency response.
Technical specifications
Sensitivity: 86dB (2.83V / 1m)
IEC power handling: 180W
Impedance: 4 ?
Frequency Response (±3dB): 39Hz-23kHz
Housing principle: bass reflex, on the back
Crossover: 2-way
Crossover frequency: 2200Hz
Crossover typology: 2nd order
Data sheet for Contour i part 1
Woofer: 18cm MSP
Midrange: -
Tweeter: 28mm Esotar2i
Weight: 14kg
Dimensions (W x H x D): 215x440x360 mm
Dimensions with feet and cover (W x H x D): 215x440x396 mm
| Color: | black high gloss |
|---|---|
| Condition: | new goods |
| Device depth mm: | 360 |
| Device height mm: | 440 |
| Device width mm: | 215 |
| Efficiency: | 86 |
| Frequency response: | 39Hz - 23kHz |
| Impedance in ohms: | 4 |
| Number of paths: | 2 |
| Product type: | floorstanding speaker |
| Series: | contour i |
| Total power W: | 180 |
