Blaze PowerZone Connect 1502 DSP Endstufe
€1,902.00
per Piece incl. VAT / incl. Shipping
Available in 7 days, delivery time 1-3 days
GermanyWe ship your goods quickly and safely with DHL. After shipping you will receive a tracking number for package tracking.
The PowerZone Connect 1502 from the Connect 2U Series is a powerful DSP-enabled Class-D amplifier designed for maximum reliability, high efficiency, and highly flexible system configuration. It offers powerful audio processing and is ideal for large-scale, professional installation projects in educational institutions, corporate venues, event venues, and retail settings.
Compatibility with Lo-Z and Hi-Z speaker systems
With its ability to power both low-impedance loudspeakers (2 Ω to 16 Ω) and constant-voltage speaker systems (70V/100V), the PowerZone Connect 1502 is extremely adaptable. Integrated automatic power-sharing technology enables proportional distribution of output power across all channels—in both Lo-Z and Hi-Z modes. This ensures efficient use of amplifier power, regardless of the speaker architecture used.
Compact 2U design with high power density
Despite its impressive performance, the amplifier boasts a compact 2U rack format, allowing for easy integration into existing AV racks or equipment rooms. This design saves valuable space while providing the power and connectivity required for modern audio environments. The PowerZone Connect 1502 is therefore particularly well-suited for applications requiring high performance in a confined space.
Wireless setup via integrated wireless access point
A special highlight of the Connect 1502 is the integrated Wireless Access Point (WAP). This enables a direct Wi-Fi connection to the amplifier, allowing installers and technicians to quickly commission the system without the need for a separate network infrastructure. The simple connection ensures a seamless setup process – ideal for flexible and mobile installations.
Intuitive control with the PowerZone Control web app
The PowerZone Control web app is seamlessly integrated into all Connect amplifiers and offers a user-friendly, browser-based interface for configuring the entire audio setup. With numerous DSP features such as equalizer, limiter, signal routing, volume control, crossover, and more, it allows for fine-tuning to the acoustic requirements of any project – all without the need for external software.
TECHNICAL DATA
- 1500W DSP-capable Class-D amplifier with 2 channels
- 2-RU design
- Output Power @ 2 O: 2 x 750 W (SE)
- Output Power @ 4 O: 2 x 750 W (SE), 1 x 1500 W (BTL)
- Output Power @ 8 O: 2 x 400 W (SE), 1 x 1500 W (BTL)
- Output Power @ 70V: 1 x 1200W (BTL)
- Output Power @ 100V: 1 x 1500W (BTL)
- Full matrix DSP configuration via PowerZone Control web app (integrated)
- Hybrid power distribution in both Low-Z and High-Z
- UREC universal power supply with PFC
- S/PDIF input/output
- Configurable GPIO
- ErP and Energy Star compliant
- Dimensions: 88 x 440 x 332 mm
| Color: | black |
|---|---|
| Condition: | new item |
| Device depth mm: | 332 |
| Device height mm: | 88 |
| Device width mm: | 440 |
| Product type: | Power amplifier |
Safety Information
Product-specific safety instructions can be found in the operating manual.
