Blaze PowerZone Connect 2004 DSP Power Amp

The PowerZone Connect 2004 from the Connect 2U series is a modern Class-D amplifier with integrated DSP technology, engineered for maximum reliability, flexibility, and professional audio quality. This model is ideal for medium to large audio installations in conference centers, educational institutions, commercial properties, or public facilities where top performance meets robust operational reliability.

Universal speaker compatibility with intelligent power sharing

Thanks to its ability to power both low-impedance loudspeakers (between 2 and 16 ohms) and transformer-coupled systems (with 70V/100V constant voltage), the PowerZone Connect 2004 offers exceptionally flexible integration into a wide variety of applications. Integrated power-sharing technology enables even, proportional power distribution in Lo-Z and Hi-Z modes, optimally utilizing available resources—regardless of the loudspeaker type or system architecture used.

Space-saving 2U chassis with high performance

With its compact 2U rack size, the amplifier is ideal for applications requiring both high output power and efficient space utilization. Its robust construction allows for reliable integration into equipment cabinets or AV racks, even in confined spaces. The PowerZone Connect 2004 combines power and versatility in a convenient format for professional requirements.

Wireless system setup via integrated Wi-Fi

A special feature of this model is the built-in Wireless Access Point (WAP), which enables a direct wireless connection to the device configuration. Installers can access the device directly via smartphone, tablet, or laptop without any additional network infrastructure and easily configure it – a particularly practical solution for flexible setups or mobile applications.

User-friendly control with the PowerZone Control web app

For quick and easy setup and precise system adjustment, the amplifier is equipped with the PowerZone Control web app. This browser-based user interface offers a wide range of DSP functions, including equalizer, limiter, delay, signal routing, volume control, crossover settings, and much more. This allows the system to be individually and efficiently tuned to the acoustic conditions of any location.

TECHNICAL DATA

• 2000W DSP-capable Class-D amplifier with 4 channels
• 2-RU design
• Output Power @ 2 O: 4 x 500 W (SE)
• Output Power @ 4 O: 4 x 500 W (SE), 2 x 1000 W (BTL)
• Output Power @ 8 O: 4 x 250 W (SE), 2 x 1000 W (BTL)
• Output Power @ 70 V: 2 x 1000 W (BTL)
• Output Power @ 100V: 2 x 1000W (BTL)
• Full matrix DSP configuration via PowerZone Control web app (integrated)
• Hybrid power distribution in both Low-Z and High-Z
• UREC universal power supply with PFC
• S/PDIF input/output
• Configurable GPIO
• ErP and Energy Star compliant
• Dimensions: 88 x 440 x 332 mm
