Diverse StarTech 1-Port RS-232 Server

StarTech 1-Port RS232

Serial Ethernet device server with PoE

A high-performance 1-port RS232 serial Ethernet device server with Power over Ethernet (PoE) that allows you to connect, configure, and remotely control RS232 serial devices over an IP network. Ideal for industrial, security, or commercial applications where serial devices need to be operated over long distances.

Thanks to PoE support, the device can be powered via a single Ethernet cable – ideal for installations in hard-to-reach locations without an available power outlet.

Main features

• 1 RS232 port for serial devices
• PoE-capable – no external power supply required
• 10/100 Mbps RJ45 LAN port
• Maximum data transfer rate of 115.2 kbit/s per port
• Supports standard Ethernet and protocols such as UDP, TCP, IP, HTTP, DHCP, ICMP and ARP-Ping
• Auto-Crossover (MDI/MDI-X) support
• Operating system compatibility: Windows 2000, XP 32-bit, Vista 32-bit
• Wall-mountable for flexible use
• Areas of application
• Industrial automation: CNC machines, process control, serial printers
• Security solutions: access control, UPS systems, cameras
• POS systems: card readers, cash registers, barcode readers
• Building automation: lighting, temperature control
• Healthcare: patient monitoring, ward equipment
• Hotel & catering industry: invoice printers, input devices, card readers
• The StarTech.com Advantage
• Flexible installation thanks to PoE – ideal for locations without power outlets
• Access serial devices over the Internet – remote management made easy
• Central management of multiple units – easy control via a single PC

Specifications

Warranty: 2 years
LED indicators: Heartbeat, Link/Activity, 10/100 Mbps
Industry standard: IEEE 802.3af Power over Ethernet
Maximum data transfer rate: 115.2 kbit/s
Data bits: 6, 7, 8
Stop bit: 1, 2
MTBF (mean operating time): 233,403 hours
Supported protocols: UDP, IP, TCP, ICMP, HTTP, DHCP, ARP ping
Color: Black
Housing material: aluminum
Dimensions: 10.7 cm (L) × 6.6 cm (W) × 2.5 cm (H)
Weight: 259.0 g (9.1 oz)
Operating system compatibility: Windows 2000, XP (32-bit), Vista (32-bit)
Patents and licenses:
US Patent Nos. 5,406,260 (expired), 6,650,622, 7,457,250, 8,155,012, 8,902,760, 8,942,107, 9,019,838, 9,049,019
US Patent Application Nos. 14/695,456, 14/726,940
Connectors: 1 × DB-9 (9-pin, D-Sub), 1 × RJ-45
Power supply: With AC adapter
Input voltage: 100–240 V AC / 19.5 V DC
Input current: 0.3 A
Output voltage: 12 V DC
Output current: 0.1 A
Polarity (center tip): Positive
Plug type: M
Power consumption: 1.2 W
Operating temperature: 0 °C to 55 °C (32 °F to 131 °F)
Storage temperature: -20 °C to 85 °C (-4 °F to 185 °F)
Humidity: 5% to 95% relative humidity
Packaging dimensions: 29.4cm (L) × 19.2cm (W) × 7.0cm (H)
Shipping weight: 0.9 kg (2.1 lb)
Packaging unit: 1
Scope of delivery: 1 × Serial device server, 1 × Universal power adapter (NA/UK/EU), 1 × Instructions
