JVC DLA-RS3200 8K E-Shift 4K HDR Laser Projector

D-ILA projector DLA-RS3200

The DLA-RS3200 is JVC's ultimate D-ILA projector, equipped with the latest technology to give you an outstanding cinema experience. With the third generation of the 0.69 inch D-ILA chip and native 4K resolution, the DLA-RS3200 sets new standards in image quality and impresses with impressive black levels, high light output and brilliant details.

next-generation technology
The DLA-RS3200 uses advanced 2nd generation 8K/e-shiftX technology that doubles the resolution of a 4K signal by shifting each frame in all four directions. This precise pixel shifting achieves almost pixel-perfect 8K resolution , resulting in exceptional sharpness and detail, especially with 8K sources. The result is a razor-sharp, lifelike projection that makes you feel like you're in the middle of the action.

Outstanding black level and high light output
Thanks to the third generation of the 0.69 inch 4K D-ILA chip and a powerful BLU-Escent laser light source, the DLA-RS3200 offers an impressive contrast ratio of 100,000:1 . In combination with the dynamic laser light control , the light source is automatically adjusted to provide the highest precision even in the darkest scenes. This enables a dynamic contrast performance of 8:1 , where the light source is switched off completely in extremely dark scenes. The result is an extremely detailed image that corresponds almost perfectly to human perception.

HDR for an unforgettable experience
The DLA-RS3200 supports all popular HDR formats including HDR10 , HLG and the latest HDR10+ with dynamic metadata. This enables precise and detailed reproduction of HDR content with enormous brightness range, extended BT.2020 color space and 10-bit gradations . Combined with the higher light output and superior contrast, HDR becomes an unforgettable experience that rewards you with a top-class cinema experience.

Improved HDR display with Frame Adapt HDR
The 2nd generation of Frame Adapt HDR technology adjusts the brightness, color and detail of each individual image in real time, based on the maximum brightness of each scene. The improved tone mapping algorithm ensures HDR display with greater color depth and resolution. This means that HDR content is displayed brighter, more colorful and with a greater dynamic range, which further increases the image quality.

Deep Black Tone Control for realistic night scenes
The Deep Black Tone Control function ensures even more precise adjustment of the black level in dark scenes in Frame Adapt HDR mode . Night scenes or dimly lit interiors in particular benefit from this technology, which makes the lighting situation appear even more realistic and significantly expands the contrast range.

Experience next-generation cinema quality with the DLA-RS3200 – a projector that leaves nothing to be desired and turns your home cinema into an incomparable experience.

equipment

• 3rd generation of the 0.69 inch D-ILA panel with native 4K resolution (4096 x 2160)
• 2nd generation 8K/e-shiftX technology for image reproduction with 8K resolution
• New BLU-Escent laser light unit
• High light output of 2,700 lumens for color-fast and dynamic images
• All-glass lens with 65 mm diameter consisting of 17 elements in 15 groups
• Native contrast ratio of 100,000:1 results in a dynamic contrast ratio of 8:1
• 2 HDMI inputs (48 Gpbs, HDCP 2.3) for signals up to 8K60P and 4K120P
• True-to-original playback of HDR10+ content by automatically adjusting the image parameters to the master information contained in the HDR stream
• The Frame Adapt HDR function ensures dynamic adaptation of HDR10 content with high image resolution. It analyses each individual image of the HDR10 content in real time and adjusts the dynamic range. In addition, the representation of the brightness levels and colour depth has been increased from 12 to 18 bits. Frame Adapt HDR ensures extremely precise reproduction of all brightness and colour shades of scenes with a wide variety of lighting situations.
• The Theater Optimizer function, in conjunction with Frame Adapt HDR, permanently ensures optimal brightness and color representation in relation to the screen size used and the gain factor. Brighter and more dynamic HDR images thanks to the HDR Quantizer function with new Auto (Wide) Level mode.
• “Auto Tone Mapping” function for optimal display of HDR10 content through automatic adaptation to the mastering data
• New FILMMAKER MODE™ for faithful reproduction according to the producer's intention.
• New image mode 'Vivid' for SDR images
• DML (Display Mastering Luminance) controls the dynamic range of the image for optimal HDR display.
• Automatic detection and image optimization of HDR10 content
• Clear Motion Drive ensures smooth motion reproduction up to 4K60P (4:4:4) and has been significantly improved in the accuracy of motion image compensation.
• ISF C3 mode (Certified Calibration Controls) for optimal calibration for specific projection environments
• 6-axis color management system
• In installation mode, optics settings, pixel adjustment, masking, screen adjustment, installation situation, keystone correction, aspect ratio and anamorphic mode can be saved for different situations.
• The extended color space exceeds DCI P3 and produces lifelike images with rich colors
• Using an optical sensor and proprietary software*, an optimal calibration can be performed in a few simple steps to adjust for changes in optical properties caused by the projector's installation situation. Auto-calibration optimizes all essential elements of the image, including color balance, gamma properties, color space and color control.
• Autocalibration with optical sensor
• Wireless transmission for 3D projection: Optional wireless transmission system consisting of the battery-operated 3D glasses PK-AG3 and the 3D synchro transmitter PK-EM2

Technical data

device in general

• D-ILA technology : Yes
• Chip Type : 3rd generation 0.69 inch 4K D-ILA chip
• Native resolution : 4096 x 2160
• Number of chips : 3
• 8K/e-Shift X Technology : Yes
• Resolution : 8192 x 4320

light source

• Laser light unit : Yes
• Type : BLU-Escent laser diode
• Lifespan of the light unit (standard mode) : 20,000 hours


• Brightness in ANSI lumens : 2700 lumens
• Contrast Ratio (Dynamic) : 8:1
• Native contrast ratio : 100,000:1
• Dynamic luminous flux control : Yes
• Modes : Mode 1 (light), Mode 2 (strong), Off
• Manual aperture control : Yes
  • Adjustment range : - 15 (stops) to 0 (open aperture)
• DCI P3 color space : Yes
• 100% REC 709 Color Space : Yes
• Color depth : 12 bit
• ISFccc Certification : Yes

HDR

• HDR10 : Yes
• HDR10+ : Yes
• Frame Adapt HDR function : Yes
• Theater Optimizer Function : Yes
• Hybrid Log Gamma (HLG) signal detection : Yes
• Auto Tone Mapping : Yes
• Display of mastering information : Yes
  • Mastering data : MaxCLL and MaxFALL display
• HDR image modes : BT.709 / BT.2020 / DCI / HDR
• Deep Black Tone Control : Yes

lens

• Zoom : 2x
• Projection ratio (projection distance to image width) : 1.43 - 2.92:1
• Diameter : 65 mm
• Material : all-glass
• Construction : 17 elements in 15 groups, aluminum body
• Lens Shift function : Yes
  • Horizontal adjustment range : ± 34 %
  • Vertical adjustment range : ± 80 %
• Motorized functions : zoom, shift, focus
• Projection diagonal size : 60 - 200 inch
• Lens setting memory function : Yes
  • Number of storage spaces : 10
• Lens cap : Yes

HDMI

• HDMI inputs : Yes
  • Number of inputs : 2
  • Data rate : 48 Gbps
  • HDCP Version : 2.3
  • signal inputs :
    • 8K60P
    • 4K120P
    • 4K60P
    • Video resolutions: 480p, 576p, 720p, 1080i, 1080p, 3840 x 2160p, 4096 x 2160p, 7680 x 4320p
    • PC resolutions: VGA to WQHD (120)
  • Input level adjustable : Auto, Standard, Enhanced, Super White
  • Color Space Range : Auto, YCbCr444, YCbCr422, RGB

connections

• Trigger output : Yes (mini jack, 3.5mm)
• Power supply : DC 12V / 100mA
• 3D display : Yes (Mini DIN 3-pin)
• LAN connection : Yes (RJ45)
• RS-232 : Yes (D-sub 9-pin)
• Firmware update : Yes (USB Type A)

3D

• 3D support : Yes
• 3D Formats : Frame Packing, Side-by-Side, Top & Bottom
• Resolutions :
  • Frame Packing: 720p 60/50, 1080p 24
  • Side by Side: 720p 60/50, 1080p 60/50/24, 1080i 60/50
  • Top & Bottom: 720p 60/50, 1080p/24
• 3D Synchro Emitter (optional) : Yes, PK-EM2
• 3D glasses (optional) : Yes, PK-AG3

image settings

• Picture modes : Natural, Cinema, Film, Vivid, HDR10+, Frame Adapt HDR, HDR10, HLG, Pan_PQ, 6 User Modes
• Color temperatures : Xenon 1, Xenon 2, 5500K, 6500K, 7500K, 9300K, High Bright, HDR10+, HDR10, HLG, Custom 1, Custom 2
• Gamma processing depth : 12 bit
• Gamma settings : HDR (Auto), HDR(PQ), HDR(HLG), 2.2, 2.4, 2.6, Cinema 1, Cinema 2, Film 1, Film 2, Pana_PQ, 3 Custom Modes
• Color management : 6-axis color management system
• MPC : Yes
• Filmmaker Mode : Yes
• 'Low Latency' mode : Yes
• Clear Motion Drive : Yes
• Motion Enhance : Yes
• Auto Calibration : Yes (Optional Probe needed)
• Installation mode : Yes
  • Number of storage spaces : 8
• Saveable settings : Lens settings, pixel adjustment, masking, anamorphic mode, screen settings, projection mode, keystone correction, aspect ratio
• Anamorphic modes : 4 modes (A, B, C, D)
• Control4 SDDP : Yes

power consumption & operating environment

• Power supply : AC100-240V, 50/60Hz
• Power consumption in normal operation : 440 watts
• Power consumption in standby mode : ECO mode 0.2 W
• Standby consumption network operation :
  • LAN: 1.21W
  • RS-232C: 0.94W
  • LAN + RS232C: 1.22W
• Off timer : About 15 minutes (factory setting)
• Fan noise : 24 dB
• Eco mode : Yes
• Standby Timer : Yes
• Operating temperature : 5°C to 35°C
• Operating humidity range : 20% to 80%
• Installation angle : Horizontal +/- 5 degrees / Vertical +/- 10 degrees
• Installation altitude : Less than 2,000 m above sea level

Scope of delivery of the DLA-RS3200 D-ILA projector:

• Remote control : Yes, RM-MH27
• Quick Start Guide : Yes
• Power cord : Yes
• Batteries : Yes, 2 x AAA batteries (Micro)
