JVC DLA-RS4200 8K E-Shift 4K HDR Laser Projector

DLA-RS4200 D-ILA projector

Experience the next generation of home cinema technology with the DLA-RS4200 D-ILA projector from JVC. With a range of innovative features, this model offers stunning picture quality that will captivate you.

3rd generation 0.69 inch D-ILA chip with native 4K resolution The DLA-RS4200 uses the latest D-ILA chip technology, which offers native 4K resolution and an outstanding contrast ratio of 150,000:1. This combination guarantees razor-sharp, detailed images with incredible depth and clarity.

BLU-Escent laser with 3,300 lumens of light output The powerful BLU-Escent laser provides an impressive brightness of 3,300 lumens. This enables vivid and realistic projections that shine even in well-lit rooms without losing any detail.

Gen2 8K/e-shiftX – 8K resolution from 4K sources The second generation of JVC's own 8K/e-shiftX technology makes it possible to upscale 4K content to impressive 8K resolution. By precisely shifting the sub-images, the finest details become visible, even with 8K sources, which ensures outstanding sharpness.

HDR with dynamic brightness and color depth The DLA-RS4200 supports all common HDR formats, including HDR10, HLG and HDR10+ with dynamic metadata. These technologies enable precise color reproduction and a realistic representation of the entire brightness range, resulting in films with an intense and lifelike picture quality.

2nd generation Frame Adapt HDR - real-time image adjustment The second generation of Frame Adapt HDR analyzes every scene in a film and adjusts brightness, color and detail in real time. This advanced algorithm ensures that HDR content is displayed with an even higher color depth and resolution, giving you an even more dynamic image.

HQ all-glass lens for perfect 4K & 8K display The specially developed HQ all-glass lens of the DLA-RS4200 with 18 optical elements ensures precise display of 4K and 8K content without distortion. The ED lenses minimize chromatic aberrations and color fringes, even when using the lens shift, for a clear, detailed projection.

Fantastic black level and high light output Thanks to the third generation of the D-ILA chip and the dynamic laser light control, the DLA-RS4200 achieves a contrast ratio of 8:1. In extremely dark scenes, the light is switched off completely to achieve a deep black level and optimize the image to the maximum - for a lifelike, cinema-like projection.

8K60p input for ultra-high-resolution 8K signals With support for 8K60p inputs, the DLA-RS4200 offers ultra-high-resolution image display. So you can enjoy the latest 8K content in all its detail.

4K120p input optimized for video games The 4K120p input with low latency, which is particularly suitable for video games, ensures an unforgettable gaming experience. This guarantees optimal synchronization between image display and operation, even in fast, action-packed games.

The DLA-RS4200 D-ILA projector from JVC sets new standards in home cinema and projector technology. With outstanding picture quality, advanced HDR display and support for 4K and 8K content, this projector offers an unparalleled cinema experience in your own four walls.

equipment

• 3rd generation of the 0.69 inch D-ILA panel with native 4K resolution (4096 x 2160)
• 2nd generation 8K/e-shiftX technology for image reproduction with 8K resolution
• New BLU-Escent laser light unit
• High light output of 3,300 lumens for color-fast and dynamic images
• Native contrast ratio of 150,000:1 and dynamic contrast of 8:1 thanks to dynamic light source control
• 2 HDMI inputs (48 Gpbs, HDCP 2.3) for signals up to 8K60P and 4K120P
• True-to-original playback of HDR10+ content by automatically adjusting the image parameters to the master information contained in the HDR stream
• The Frame Adapt HDR function ensures dynamic adaptation of HDR10 content with high image resolution. It analyses each individual image of the HDR10 content in real time and adjusts the dynamic range. In addition, the representation of the brightness levels and colour depth has been increased from 12 to 18 bits. Frame Adapt HDR ensures extremely precise reproduction of all brightness and colour shades of scenes with a wide variety of lighting situations.
• The Theater Optimizer function, in conjunction with Frame Adapt HDR, permanently ensures optimal brightness and color representation in relation to the screen size used and the gain factor. Brighter and more dynamic HDR images thanks to the HDR Quantizer function with new Auto (Wide) Level mode.
• New FILMMAKER MODE™ for faithful reproduction according to the producer's intention*
• “Auto Tone Mapping” function for optimal display of HDR10 content through automatic adaptation to the mastering data
• Automatic detection and image optimization of HDR10 content
• All-glass lens with 100 mm diameter consisting of 18 elements in 16 groups
• In installation mode, optics settings, pixel adjustment, masking, screen adjustment, installation situation, keystone correction, aspect ratio and anamorphic mode can be saved for different situations.
• The extended color space exceeds DCI P3 and produces lifelike images with rich colors
• Clear Motion Drive ensures smooth motion reproduction up to 4K60P (4:4:4) and has been significantly improved in the accuracy of motion image compensation.
• The Low Latency mode reduces the delay in image processing to a minimum and ensures optimal synchronization of operation, image and sound, even with image signals with high bandwidth.
• ISF C3 mode (Certified Calibration Controls) for optimal calibration for specific projection environments
• 6-axis color management system
• Autocalibration with optical sensor
• Wireless transmission for 3D projection: Optional wireless transmission system consisting of the battery-operated 3D glasses PK-AG3 and the 3D synchro transmitter PK-EM2
• New image mode 'Vivid' for SDR images
• DML (Display Mastering Luminance) controls the dynamic range of the image for optimal HDR display.

Technical data: DLA-RS4200 D-ILA projector

device in general

• D-ILA technology: Yes
• Chip Type: 3rd Generation 0.69 inch 4K D-ILA Chip
• Native resolution: 4096 x 2160
• Number of chips: 3
• 8K/e-Shift X Technology: Yes
• Resolution: 8192 x 4320

light source

• Laser light unit: Yes
• Type: New BLU-Escent Laser Diode
• Lifespan of the light unit (standard mode): 20,000 hours


• Brightness in ANSI lumens: 3300 lumens
• Contrast ratio (dynamic): 8 : 1
• Native contrast ratio: 150,000:1
• Dynamic luminous flux control: Yes
• Modes: Mode 1 (light), Mode 2 (strong), Off
• Manual aperture control: Yes
• Adjustment range: -15 (stops) to 0 (open aperture)
• DCI P3 color space: Yes
• 100% REC 709 Color Space: Yes
• Color depth: 12 bit
• ISFccc Certification: Yes

HDR

• HDR10: Yes
• HDR10+: Yes
• Frame Adapt HDR Function: Yes
• Theater Optimizer Function: Yes
• Hybrid Log Gamma (HLG) signal detection: Yes
• Auto Tone Mapping: Yes
• Display of mastering information: Yes
• Mastering data: MaxCLL and MaxFALL display
• HDR image modes: BT.709 / BT.2020 / DCI / HDR
• Deep Black Tone Control: Yes

lens

• Zoom: 2x
• Projection ratio (projection distance to image width): 1.35 - 2.75 : 1
• Diameter: 100 mm
• Material: all-glass
• Construction: 18 elements in 16 groups, aluminum body
• Lens Shift function: Yes
• Horizontal adjustment range: ± 43 %
• Vertical adjustment range: ± 100 %
• Motorized zoom function: Yes
• Motorized shift function: Yes
• Motorized focus adjustment: Yes
• Projection diagonal size: 60 - 300 inches
• Lens setting memory function: Yes
• Number of storage spaces: 10
• Lens cap: Yes

HDMI

• HDMI inputs: Yes
• Number of inputs: 2
• Data rate: 48 Gbps
• HDCP Version: 2.3
• 8K60P signal input: Yes
• 4K120P signal input: Yes
• 4K60P signal input: Yes
• Video input signals: 480p, 576p, 720p 60/50, 1080i 60/50, 1080p 120/100/60/50/30/25/24, 3840x2160p 120/100/60/50/30/25/24, 4096x 2160p 120/100/60/50/30/25/24, 7680x4320p 60/50/30/25/24
• PC input signals: VGA / SVGA / XGA / WXGA / WXGA+ / SXGA / WSXGA+ / UXGA / WUXGA / WQHD (60) / WQHD (120)
• Input level adjustable: Auto / Standard (16-235) / Enhanced (0-255) / Super White (16-255)
• Color Space Range: Auto / YCbCr444 / YCbCr422 / RGB
• EDID modes: A or B (older hardware may require the B settings)

connections

• Trigger output: Yes (mini jack 3.5mm)
• Power supply: DC 12V / 100mA
• 3D display: Yes (Mini DIN 3-pin)
• LAN connection: Yes (RJ45)
• RS-232: Yes (D-sub 9-pin)
• Firmware Update: Yes (USB Type A)

3D

• 3D support: Yes
• 3D Formats: Frame Packing, Side-by-Side, Top & Bottom
• Resolution Frame Packing: 720p 60/50, 1080p 24
• Resolution Side-by-Side: 720p 60/50, 1080p 60/50/24, 1080i 60/50
• Resolution Top & Bottom: 720p 60/50, 1080p/24
• 3D Synchro Emitter (optional): Yes, PK-EM2
• 3D glasses (optional): Yes, PK-AG3

image settings

• Image modes: Natural, Cinema, Film, Vivid, HDR10+, Frame Adapt HDR, HDR10, HLG, Pan_PQ, 6 User modes
• Color temperatures: Xenon 1, Xenon 2, 5500K, 6500K, 7500K, 9300K, High Bright, HDR10+, HDR10, HLG, Custom 1, Custom 2
• Gamma settings: HDR (Auto), HDR(PQ), HDR(HLG), 2.2, 2.4, 2.6, Cinema 1, Cinema 2, Film 1, Film 2, Pana_PQ, 3 Custom modes
• Color management: 6-axis color management system
• Filmmaker Mode: Yes
• 'Low Latency' mode: Yes
• Clear Motion Drive: Yes
• Motion Enhance: Yes
• Auto Calibration: Yes (Optional Probe needed)
• Installation mode: Yes
• Saveable settings: lens settings, pixel adjustment, masking, anamorphic mode, screen settings, projection mode, keystone correction, aspect ratio
• Anamorphic modes: 4 modes (A, B, C, D)
• Control4 SDDP: Yes

power consumption & operating environment

• Power supply: AC100-240V, 50/60Hz
• Power consumption in normal operation: 440 watts
• Power consumption in standby mode: ECO mode 0.2 W
• Standby consumption network operation: 1.21W (LAN), 0.94W (RS-232C), 1.22W (LAN + RS232C)
• Power off timer: Approximately 15 minutes (in standby or network standby; factory setting)
• Fan noise: 24 dB
• Eco mode: Yes
• Standby Timer: Yes
• Operating temperature: 5°C to 35°C
• Operating humidity range: 20% to 80%
• Installation angle: Horizontal +/- 5 degrees / Vertical +/- 10 degrees
• Installation height: Less than 2,000 m above sea level

• Remote control: Yes, RM-MH27
• Quick Start Guide: Yes
• Power cord: Yes
• Batteries: Yes, 2 x AAA batteries (Micro)
