Clearaudio NANO Phono Headphone V2
€490.00
per Piece incl. VAT / incl. Shipping
Available, delivery time: 1-3 days
GermanyWe ship your goods quickly and safely with DHL. After shipping you will receive a tracking number for package tracking.
His meticulously selected SMD components are assembled by hand in Erlangen and tested several times. The reward for the effort is a signal-to-noise ratio of up to 84 decibels. The input impedance can be regulated by the listener. There is no loss of sound when using different moving magnet and moving coil pickups, which can produce unlimited sound volume.
The NANO Phono Headphone V2 also has a powerful headphone output in its solid aluminum housing for undisturbed listening pleasure at the highest level.
Technical data
| MODE: | MM / MC switchable with jumper (on the bottom) Subsonic filter can be switched on with a jumper (on the underside) |
| GAIN AT 1 KHZ: | 34 dB (MM operation) 54 dB (MC operation) |
| INPUT IMPEDANCE: | 47 kO/ 220 pF / MM operation Individual / MC operation |
| RIAA ACCURACY: | ± 0.4dB @ 20Hz - 50kHz |
| THD: | <0.04% |
| SIGNAL/NOISE RATIO: | 81 dB (A) (MM operation) 70 dB (A) (MC operation) |
| OVERsteer resistance: | 18dB/MC |
| MAXIMUM OUTPUT VOLTAGE: | 10V rms (1kHz) |
| CUTTING CHARACTERISTICS EQUALIZATION: | According to RIAA (time const.: 75 µs / 318 µs / 3180 µs) |
| CHANNEL SEPARATION: | > 80 dB at 1 kHz, opposite channel short-circuited |
| OUTPUT RESISTANCE: | 75 O |
| INPUTS: | asymmetrical (CINCH) |
| OUTPUTS: | asymmetrical (CINCH) optional headphone output (jack: 3.5 mm) |
| POWER CONSUMPTION: | Max. power consumption: 2.3 watts In operation: 2.3 watts Standby mode: < 0.3 watts Powered off: 0.0 watts |
| POWER SUPPLY: | ± 18V DC / 300mA (external power supply, plastic housing) |
| WEIGHT: | approx. 500 g (preamplifier and power supply) |
| DIMENSIONS (W/D/H): | approx. 85 × 106 × 25 mm |
| Color: | silver |
|---|---|
| Condition: | new item |
| Device depth mm: | 106 |
| Device height mm: | 25 |
| Device width mm: | 85 |
| Product type: | Preamplifier |
Manufacturer
clearaudio electronic GmbH
Spardorfer Strasse 150
91054 Erlangen
Deutschland
info@clearaudio.de
Safety Information
Product-specific safety instructions can be found in the operating manual.
