Arcam SA35 compact integrated amp incl. streaming client

ARCAM SA35

Expertly crafted in Cambridge, UK, the ARCAM SA35 offers state-of-the-art technologies to preserve and reproduce the finest sounds with all their nuances and details.

Exquisite sound quality and innovative technology

The ARCAM SA35 features a completely new digital audio and streaming platform. This six-layer platform utilizes a ground plane to minimize noise and interference. With ESS's latest Hyperstream iV DAC topology in a balanced configuration and advanced jitter elimination, unparalleled sound quality is achieved. The new linear toroidal transformer design ensures low-noise operation and maximum efficiency in standby mode.

5th generation Class G amplifier

Our 5th generation Class G amplifier design guarantees the best sound quality and dynamics. New, carefully selected components and materials ensure uncompromising sound performance.

User-friendly features

The ARCAM SA35 features a high-resolution 6.5-inch display that clearly shows album art and metadata. Connecting to your home network via Wi-Fi is quick and easy thanks to the ARCAM Radia app. Enjoy instant playback via Apple AirPlay, Google Chromecast, Spotify Connect, Tidal Connect, and Roon.

Versatile connectivity options

With subwoofer outputs and Dirac Live room correction, the ARCAM SA35 offers the flexibility to deliver exceptional sound in any room with your choice of speakers. It supports MM & MC phono inputs, HDMI eARC, and dual subwoofer outputs.

Key features of the ARCAM SA35:

• Ultra-high-resolution streaming platform
• ARCAM Class G amplification with 2x 120W ultra-low distortion power
• MM & MC Phono Inputs
• HDMI eARC input
• Dual subwoofer outputs and Dirac Live room correction
• High-resolution display for clearly visible album art and metadata
• Support for Apple AirPlay, Chromecast, Spotify Connect and Tidal Connect
• Setup with the ARCAM Radia app for presets, internet radio and podcasts
• Supports up to 32-bit/768 kHz Hi-Res Audio
• Roon Ready (post-launch)

Experience unparalleled sound quality and state-of-the-art streaming technology with the ARCAM SA35. Perfect for music lovers who refuse to compromise.

TECHNICAL DATA

Continuous power (0.5% THD), per channel

• 2 channels operated, 20Hz - 20kHz, 80: 120W
• 2 channels operated, 1kHz, 40: 220W
• Harmonic distortion, 80% power, 80° at 1kHz: 0.002%

Analog inputs

Number of inputs: 3 (RCA pairs)
Phono inputs: MM and MC
Frequency response: 20Hz - 20kHz ± 0.2dB
Signal-to-noise ratio (A-weighted, ref. 50W, 1V input): 106dB

Digital inputs

Supported streaming media: FLAC, WAV (LPCM), AAC, ALAC, AIFF, DSD (up to 1024 kbps), MP3, MP4, OGG, WMA
Supported streaming bit depths: 16, 24, 32
Supported streaming sampling rates (kHz): Up to 768 kHz
Gapless playback: Yes
Digital audio inputs: 1x HDMI ARC, 2x coaxial (RCA), 2x optical (Toslink)
Supported digital input bit depth: 16, 24
Supported digital input sampling rates (kHz): Up to 192 kHz
Frequency response (filter 1): 20Hz - 20kHz ± 0.2dB
Signal-to-noise ratio (A-weighted, ref. 50W, 0dBFS): 110dB

Wireless specifications

Bluetooth

• Profile: 5.2; A2DP Sink/Source, AVRCP, BLE, aptX, aptX HD, aptX Adaptive, AAC
• Transmitter frequency and power: 2.402 MHz to 2.480 MHz: <13dBm

Wi-Fi

• Network: IEEE 802.11 a/b/g/n/ac/ax (2.4GHz/5GHz)
• 2.4G Wi-Fi transmitter frequency range and power: 2400-2483.5 MHz (USA 11 channels, Europe and others 13 channels) <20dBm
• 5G Wi-Fi transmitter frequency range and power:
  • 5150-5250 MHz <23dBm
  • 5250-5350MHz & 5470-5725MHz <20dBm
  • 5725-5850 MHz <14dBm

Generally

Mains voltage: 100V or 110-120V or 220-240V, 50-60Hz
Power consumption (maximum): 800W
Power consumption (standby): <0.5W
Dimensions (W x D (incl. speaker connections) x H (incl. feet)): 431 x 344 x 98 mm
Weight (net): 12 kg
Weight (packaged): 14 kg

Included accessories

• power cable
• Remote control with 2 x AAA batteries
• Measuring microphone
• 5m USB cable
• Quick Start Guide
• Important safety instructions
