Arcam A15 Integrated Amplifier

Arcam A15 integrated amplifier

The ARCAM A15 is a powerful powerhouse with 80 watts of power per channel. Ideal for use with tower speakers, in spacious rooms and at higher volumes.

The 'A' in ARCAM represents Amplification - our core competency. The A15 is the result of over 45 years of amplifier development and production. New components and materials have been thoroughly analyzed and tested to ensure outstanding sound performance.

For an instant music experience out of the box, the ARCAM A15 is equipped with a Bluetooth solution that uses Qualcomm AptX Adaptive technology. This delivers up to 24-bit HD audio for the highest sound quality from your phone or tablet, regardless of the source being played. It can also be connected to Bluetooth headphones to provide a pleasant listening experience even in the dark.

High-resolution digital audio inputs are available for Hi-Res audio.

As with every ARCAM integrated amplifier, special attention has been paid to the integrated phono stage to ensure that your records sound as lush and immersive as possible.

At a glance:

• ARCAM Class AB amplification - ensures brilliant musicality
• 80W per channel 8O - supplies speakers with dynamics.
• Bluetooth with aptX™Adaptive Technology - for the best sound with maximum comfort
• Specially selected components and materials - for the best sound quality
• Wired or wireless headphones - connect your headphones with or without a cable for quiet listening
• Completely new Radia design - targeted yet playful
• MM phono stage - ready for turntables
• Hi-Res digital audio inputs
• Plastic-free packaging - for easy disposal of natural materials

Technical data:

Continuous power output (0.5% THD), per channel
2 channels driven, 20Hz - 20kHz, 8O 80W
2 channels driven, 1kHz, 4O 120W
Harmonic distortion, 80% power, 8O at 1kHz 0.002%

Analog inputs
Number of inputs 3 (RCA pairs)
Signal/noise ratio (A-wtd, ref. 50W, 1V input) 106dB
Frequency response 20Hz—20kHz ± 0.2dB

Phono (MM) input
Input impedance 47kO + 100pF
Frequency response (ref. RIAA curve) 20Hz—20kHz ± 1dB
Signal/noise ratio (A-wtd, ref. 50W, 0dBFS) 109dB

Digital inputs
Supported Sample Rates (kHz)
Coaxial (RCA) 192, 176.4, 96, 88.2, 48, 44.1
Optical (Toslink) 192, 176.4, 96, 88.2, 48, 44.1

Bit depths (bit) 24, 16
Frequency response (fi lter 1) 20Hz—20kHz ± 0.2dB
Signal/noise ratio (A-wtd, ref. 50W, 0dBFS) 109dB

Headphone output
Maximum output level (RMS) into 32O/300O 2.5V/5Vrms
Load range 16O - 2kO

general
Mains voltage 100V or 110-120V or 220-240V, 50-60Hz
Power consumption (maximum) 500W
Power consumption (standby) <0.5W
Dimensions W x D (including speaker terminals) x H (including feet) 431 x 344 x 98mm
Weight (net) 10kg
Weight (packed) 13kg

Supplied accessories
Main's lead(s)
Remote control with 2 x AAA batteries
Quick Start Guide
Important Safety Instructions
