Classe Delta Stereo Amplifier black

When there is not enough space for two mono amplifiers, the Delta STEREO is the solution for performance without compromise.

The highlights at a glance

• Up to 35 watts (MONO) or 12.5 watts per channel (STEREO) in pure Class A operation and control with
  low impedance eliminate switching distortions at low signal levels and guarantee a sovereign
  performance with any type of speaker.
• The in-house ICTunnel™ technology for active cooling ensures an ideal operating temperature for
  maximum performance and reliability even under maximum loads.
• Special and premium components such as the 22 four-pole capacitors from Mundorf®, the custom-made
  Toroidal transformer and hand-built 4- or 6-layer printed circuit boards ensure excellent performance.
• Furutech® rhodium-plated RCA and Torque Guard speaker terminals offer greater durability and performance than gold terminals.
• Navcom® custom feet dampen vibration and counteract microphonic effects, improving overall clarity.
• Level meters provide diagnostic feedback as well as an aesthetic visual representation of the auditory and
  noticeable performance.

The first 12.5 watts of power fully correspond to the Class A amplifier class. With a total of 250 watts per channel (more than 350 watts per channel at 2 ohms), the compact, powerful amplifier supplies every speaker in an impressively sovereign way.

• Up to 12.5 watts per channel in pure Class A operation
• A total of 250 watts per channel
• Stable, high-quality power supply
• Custom made toroidal transformer

clarity

The first 12.5 watts of power fully correspond to the Class A amplifier class. With a total of 250 watts per channel (more than 350 watts per channel at 2 ohms), the compact, powerful amplifier supplies every speaker in an impressively sovereign way.

• Up to 12.5 watts per channel in pure Class A operation
• A total of 250 watts per channel
• Stable, high-quality power supply
• Custom made toroidal transformer

design

Strong appearance: The design of the Delta STEREO is an expression of its performance. It looks fantastic in any setting and facility.

Exquisite finishes and two custom-designed illuminated meters make the power output display for both channels eye-catching.

The design concept of the Delta Series is to create a monument to sound. And the amp looks just as powerful as it sounds.

Dimensions

Width: 444 mm (17.50 in)

Depth: 492mm (19.37in)

Height: 222mm (8.74in)

Weight

Gross weight: 52.8 kg (116.4 lbs)

Net weight: 46.4 kg (102.3 lbs)

General

Frequency response (-3dB, 50O source impedance):

1Hz - 650kHz

Continuous power per channel (at 1kHz, 0.1% THD+N):

12.5W / 8O Class A
250W / 8O
500W / 4O (at constant AC voltage)
350W / 2O (at constant AC voltage)

Harmonic distortion (measurement bandwidth: 500kHz, 25Vrms in 4O or 8O):

<0.0016% at 1kHz
<0.002% at 10kHz
<0.003% at 20kHz

Harmonic Distortion (measurement bandwidth: 90kHz, 25Vrms in 4O or 8O):

<0.0007% at 1kHz
<0.001% at 10kHz
<0.0025% at 20kHz

Peak Output Voltage (Nominal AC Voltage):

129Vp-p in 8O
138Vp-p with no load

Input Impedance (at 1kHz, BAL / SE):

82kO

Voltage gain (at 1kHz, BAL / SE):

29dB

Intermodulation Distortion (SMPTE 4:1) (8O or 4O, BAL/SE):

<0.0018%

Intermodulation Distortion (CCIF) (8O or 4O, BAL/SE):

<0.004%

Signal-to-noise ratio (A wtd in brackets) (22kHz BW):

118dB (120dBA)

Crosstalk attenuation (one channel is operated with 250W / 8O):

124dB (100Hz), 107dB (1kHz),

90dB (10kHz)

Slew Rate:

75V / µs

Output Impedance:

0.009O (100Hz), 0.009O (1kHz),

0.012O (10kHz)

Damping factor (at 1kHz, see 8O):

850
