Sonance VX 86R - 2 Way In Wall/ In Ceiling Speaker
€379.00
per Piece incl. VAT / incl. Shipping
Available, delivery time: 1-3 days
Germany We only ship this item to the following countries: GermanyWe ship your goods quickly and safely with DHL. After shipping you will receive a tracking number for package tracking.
Sonance VX46R built-in speakers
The built-in speakers of the Visual Experience series are characterized by easy installation, excellent sound and a variety of designs. In addition to the different sizes, round, square and rectangular covers are available.
The wide range of optics makes it possible to match the shape of the installed lights and the VX built-in speakers. Different performance levels ensure the best possible music reproduction throughout the house, meeting even the highest quality standards.
All VXQ models are suitable for damp rooms.
FLEX FRAME MOUNTING SYSTEM
The Flex Frame mounting system combines an installation frame with a loudspeaker module to ensure maximum flexibility during the installation process. Choose between the proven method, which is similar to the VP series, or a two-step installation, which allows for even easier handling. Models of the VX and VXQ series with performance levels 0 and 8 are assembled in one step.
DESIGN AND OPTICS
The Visual Experience series impresses with an impressive variety of designs. Different grille sizes, grille types and form factors open up almost unlimited customization options to harmoniously integrate the speaker design into ceiling images and room furnishings.
The standard grille of the VX series is supplied in signal white (RAL9003) and is particularly durable thanks to a UV stabilizer. The slim plastic edge of the VP series has been adopted and reduced to 3 mm, retaining the proven properties such as seamless transitions and shadow-free integration. For even more design freedom, trimless grilles without a plastic edge are available separately, also in signal white (RAL9003) and with a UV stabilizer.
Preparations for flush installations are in the final development phase. The mounting plates provided for this purpose ensure perfect integration and are based on the popular installation solutions of the VP series, which will be available for all models in the future.
INDIVIDUALIZATION (CUSTOM)
Sonance offers extensive options for customizing the speaker covers, which can be designed according to individual customer requirements. The cover grilles can be painted in any desired color or laser printed with specific motifs or textures. This means that the speakers in the Visual Experience series fit seamlessly and unobtrusively into any room.
For example, you want to install speakers in a concrete-look wall? No problem! Choose between a uniform gray paint finish or an authentic laser print with a concrete texture to achieve the aesthetic you want.
Technical data
- Design : Square, Round
- Operating power : 80 watts
- Efficiency : 90 dB @ 2.83V/1m
- Frequency response : 58 Hz – 20 kHz (±3 dB)
- Impedance : 8 Ohm (nominal)
Installation dimensions :
- Installation diameter : 149 mm
- Installation depth : 118 mm
- Maximum installation depth : Up to 130 mm, up to 150 mm, up to 200 mm
| Condition: | new item |
|---|---|
| Cut-out diameter mm: | 149 |
| Efficiency: | 90 |
| Frequency response: | 58Hz - 20kHz +/-3dB |
| Impedance in ohms: | 8th |
| Installation depth mm: | 118 |
| Number of paths: | 2 |
| Product type: | Built-in speakers |
| Series: | Visual Experience series |
| Total power W: | 80 |
Safety Information
Product-specific safety instructions can be found in the operating manual.
