JVC DLA-Z1 4K

D-ILA projector

DLA-Z1

The DLA-Z1 projector combines the new native 4K D-ILA panel with the groundbreaking 'Blu-Escent' laser phosphor technology and thus enables an incredibly dense, high-resolution and unadulterated display right into every corner of the projected image. With a resolution that even surpasses Ultra HD, HDR compatibility and the high native contrast, you can enjoy fantastic, lifelike images in a never-before-seen brilliance, sharpness and naturalness. Whether movies or sports, music, documentaries or 3D films, with the DLA-Z1, the world's first THX-4K-certified projector, viewing becomes a new experience that puts everything else in the shade.

Furnishing

• High-resolution image projection with 4K resolution (4096 x 2160 pixels)
• Newly developed 0.69 inch native 4K D-ILA panel with 4096 x 2160 pixels - the world's smallest 4K panel for home cinema projectors (in October 2016)
• BLU-Escent laser light unit with blue laser diodes achieves a light output of up to 3,000 lumens and a long service life
• Due to the enormous maximum brightness, a contrast ratio of infinity: 1 is achieved
• The specially smoothed panel surface reduces light scattering and thus realizes the extremely high contrast ratio
• Light engine optimized for 4K projection with an aperture of 2.6 for efficient light output
• Playback of HDR content with a higher dynamic range thanks to the excellent contrast ratio, the extended color space and the maximum brightness of 3,000 lm
• THX 4K DISPLAY Certificate that HD and Ultra HD video content is reproduced to the highest standard and in accordance with the specifications of the film producers.
• Supports the new HDMI / HDCP 2.2 standard, which complies with all specifications of high quality 4K video signals up to 4K60p (4: 4: 4)
• Upscaling of Full HD videos to 4K resolution
• High-quality all-glass lens consisting of 18 elements in 16 groups with 100 mm lens diameter and 5 optical ED lenses to minimize chromatic aberration and any color fringing that may occur
• Multi Pixel Control for a highly realistic image display from the foremost sharpness of detail to intentional blurring in the image background
• Innovative video processing for a perfect display of movements: 'Clear Motion Drive' and 'Motion Enhance' eliminate jittering, ghosting and trailing effects and are compatible with 4K60p signals (4: 4: 4).
• Support of the Hybrid Log-Gamma, an HDR process that will be used primarily in the broadcast sector in the future.
• HDMI inputs for 4K video signals (4K60P 4: 4: 4, 4K60P 4: 2: 2/36-bit, 4K24P 4: 4: 4/36-bit at 18 Gbit / s)
• Connections: 2 x HDMI (3D, Deep Color / HDCP 2.2 / 18 Gbps), 1 x RS-232C (D-sub 9pin), 1 x LAN (RJ-45), 1 x trigger (mini jack, DC12 V / 100 mA ), 1 x 3D Sync (3-pin mini-DIN), service connection (USB Type-A)
• ISF C3 (Certified Calibration Controls) image calibration * - optimizes the image quality specifically for the individual requirements in the home theater
• Auto-calibration ** for optimal fine-tuning of the basic image parameters such as color balance, gamma values, color space and color tracking.
• * Professional calibrations can be carried out by appropriately trained JVC D-ILA dealers. ** Requires the installation of JVC's own software on the PC and an optical sensor (colorimeter).
• Wireless transmission for 3D projection: radio transmission system consisting of the battery-operated 3D glasses PK-AG3 and the 3D synchro transmitter PK-EM2
• Enormous brightness of up to 3,000 lumens thanks to the BLU-Escent laser light unit and 4K-optimized light engine

  Technical data: DLA-Z1 D-ILA Projector


  lens

  zoom

  2x optical zoom lens with motorized zoom / focus adjustment

  Projection size (screen diagonal)

  200 - 700 cm (at 16: 9 aspect ratio)

  Lamp life

  About 20,000 operating hours

  Brightness in ANSI lumens

  3,000 lm

  Contrast ratio

  Infinite: 1

  Video format

  480p, 576p, 720p 60/50, 1080i 60/50, 1080p 60/50/24, 3840 x 2160p 60/50/30/25/24, 4096 x 2160p 60/50/30/25/24

  PC input signal

  HDMI inputs

  VGA / SVGA / XGA / WXGA / WXGA + / SXGA / WSXGA +

  Video inputs (rear)

  HDMI inputs

  2 (3D / Deep Color / HDCP 2.2 / 18 Gbit / s)

  Outputs (rear)

  3D synchro

  1 (mini-DIN, 3-pin)

  Control connections

  RS232C

  1 (9-pin D-Sub)

  Trigger output

  1 (mini socket, 12 V DC / 100 mA)

  LAN (RJ45)

  1

  Image converter

  0.69-inch 4K D-ILA (4096 x 2160) x3

  Max. Resolution

  4096 x 2160 pixels

  Lens shift function

  +/- 100% vertical & +/- 43% horizontal (motorized)

  Projection lamp

  Laser unit

  Service connection

  SERVICE

  USB Type-A (for firmware updates)

  3D

  3D formats

  Frame packing

  720p 60/50, 1080p 24

  Side-by-side

  720p 60/50, 1080p 60/50/24, 1080i 60/50

  Top & bottom

  720p 60/50, 1080p / 24

  General

  Operating noise

  25 dB (lamp in energy-reduced mode)

  Power consumption

  750 W (Normal Standby: 1.5 W; Eco Mode Standby: 0.4 W)

  Power consumption in normal operation

  750 W

  Power consumption in standby mode

  0.4 W

  Power consumption in network operation

  1.4 W (LAN); 1.1 W (RS232C); 1.4 W (LAN and RS232C)

  Shutdown timer

  20 min. (Factory setting for standby and network operation)

  Dimensions: W x H x D in mm

  500 x 235 x 720

  Weight in kg

  37.5
