Pro-Ject Phono Box DS 2 Premium Phono Preamplifier
€299.00
per Piece incl. VAT / incl. Shipping
No longer available
GermanyWe ship your goods quickly and safely with DHL. After shipping you will receive a tracking number for package tracking.
Phono Box DS2
Phono preamplifier
Premium phono preamplifier for MM & MC cartridges
Phono Box DS2 is an extremely adaptable phono stage, which is ideally suited for both MM and MC systems. With the ability to switch between input impedance and capacitance, as well as gain, on the front panel, it becomes one of the most user-friendly phono stages in its price segment. It offers a pair of RCA sockets for a turntable and a pair of RCA sockets (output) to connect to a preamplifier or integrated amplifier. The housing is a robust aluminum / metal sandwich construction, which not only effectively protects against electromagnetic interference and vibrations, but is also pleasing to the eye with its aesthetic appearance. The structure of Phono Box DS2 is very linear, resulting in the best possible sound from a minimalist PCB. The high sound quality coupled with a low price makes Phono Box DS2 a real audiophile bargain!
Magnetic real wood side parts in walnut, rose nut & eucalyptus are available separately & not included in the scope of delivery.
Features
- Suitable for MM and MC systems
- Precise RIAA equalization
- Double mono construction for optimal channel separation
- Input impedance selectable on the front
- Input capacity selectable on the front
- Low-noise components
- Gold-plated connections
- Aluminum / metal sandwich housing protects against vibrations and EMI
- Available in silver or black
- Magnetic side parts in eucalyptus, rose nut and walnut available separately
Technical specifications
Input impedance 10-47 kOhm
Capacity 100/220 and 320pF
Gain 40/45/50/60/65 dB
Output voltage 500mV @ 1kHz (at 5mV input voltage @ 1kHz)
Noise floor - 80 dB V
THD + N <0.02%
THD 0.0008%
RIAA equalization within 0.5dB / 20Hz - 20kHz
Inputs 1 pair of RCA
Outputs 1 pair of RCA
Power supply 18V / 500mA DC; 110 - 240V, 50 / 60Hz
Power consumption 100 mA DC, <1 watt standby
Dimensions W x H x D 206 x 71 x 194 mm (aluminum)
240 x 72 x 194 mm (wood)
Weight 1320 g (aluminum) without power supply
1770 g (wood) without power supply
| Color: | black |
|---|---|
| Condition: | New goods |
| Device depth mm: | 194 |
| Device height mm: | 71 |
| Device width mm: | 206 |
| Material: | aluminum |
| Product type: | Phono preamplifier |
Manufacturer
Audio Tuning Vertriebs GmbH
Wirtschaftspark A5 Mistelbach/Wilfersdorf
Analogweg 1
2130 Mistelbach AUSTRIA
info@project-audio.com
Safety Information
Product-specific safety instructions can be found in the operating manual.
