Cambridge Audio Edge W Premium Power Amplifier

The finest power amp Cambridge has ever made.

The Edge W is designed to generate volume. When you turn the knob up, you can expect dynamic, powerful sound that captures all the details of your song. With only 14 selected components, the Edge W delivers the cleanest signal ever. You get stunning, unaffected British sound - nothing added, nothing left out.

Powerful and true to detail.

Despite its power, the Edge W has a particularly good reproduction of details. The sound is very well balanced, producing musical depth and clarity with every note. Its secret is the choice of its components - we made no compromises based on price, specification or measured performance. We listened carefully. Our system consists of components that deliver the best sound. The result is an amplifier that brings the original recording to life like no other device.

Only 14 components in the signal path.

Despite the minimalist exterior design, the Edge W contains complex audio technology. In order to remove barriers between you and your music, we have taken great care to use the smallest possible number of components in the signal path. As a result, the Edge W faithfully reproduces the original recording with impressively detailed, three-dimensional sound and distinctive staging and focus.

Greater detail in music.

Cambridge pioneered the use of toroidal transformers in amplifiers, which helped improve performance. At Edge, they take it a step further and use reverse-balanced dual toroidal transformers. This balances out EMI while delivering outstanding performance and consistent pitch, no matter what the volume.

Effortless performance without distortion.

A normal class A amplifier was not efficient enough for the Edge W. Cambridge instead added bias to a conventional AB amplifier to reduce distortion to inaudible levels. This specific configuration also generates less heat and makes the whole system much more efficient.

Perfect partners.

Edge Systems values perfect synchronization. Combine the Edge W with the most versatile preamp/network player (Edge NQ) to create a hi-fi system with sound reproduction and design that is second to none.

Technical specifications:

Continuous power output

100 W RMS into 8 ohms; 200 W RMS at 4 ohms

Distortion (unweighted)

< 0.002% 1kHz at rated power (8 ohms); < 0.02% 20 Hz - 20 kHz at rated power (8 ohms)

frequency response

< 3Hz - > 80kHz +/- 1dB

Signal-to-noise ratio (at 1 W into 8 ohms)

> 93d

Crosstalk at 1 KHZ

< -100dB

Signal-to-noise ratio (at full power)

> 113dB

input sensitivity

Input A1-A2 (unbalanced) 1.09Vrms

input impedances

Input A3 (balanced) 47k ohms; Input A1-A2 (unbalanced) 47k ohms

inputs

Balanced, Unbalanced

exits

Loudspeakers, loop outputs

Max power consumption

1000W

standby power consumption

<0.5W

dimensions

150x460x405mm

Weight

23.6kg
