Bluesound Professional B 170S 100 Volt Network Amplifier for One Zone

Bluesound Professional B170S - Networkable streaming stereo amplifier

The Bluesound Professional B170S is a network-enabled streaming stereo amplifier that offers a comprehensive solution for commercial music systems. The B170S combines a high-quality, low-impedance, constant-voltage stereo amplifier with a BluOS-enabled network music player. The amplifier section of the B170S delivers 2 x 80W of power at 4/8? or 2 x 100W at 70V or 1 x 100W at 100V. This provides enough power for most small to medium-sized rooms, and the thermostatically controlled fan cooling ensures reliable operation in commercial environments. The amplifier technology is extremely energy efficient and also features a standby mode that consumes only 6W of power. The constant voltage outputs allow long chains of small loudspeakers to be driven with variable power adjustments at each loudspeaker to allow local volume control.

Flexible assembly

The design of the B170S allows it to be mounted individually vertically or horizontally on or under shelves or tables or on walls. Up to six B170S units can be rack mounted side-by-side in a 3U space using the optional RM160 rack mount shelf to create a compact 12-channel system with six independent or grouped zones.

A complete stereo solution for commercial installations Integration with local network storage content PC/Mac, iOS/Android and 3rd party control Security features prevent unauthorized control Flexible and unlimited grouping of zones within a BluOS system Streaming over Ethernet for increased reliability USB input for playback from local attached drives Energy efficient amplification with both low impedance and constant voltage outputs 2 x 80W @ 4/8 ohms 2 x 100W @ 70 volts 1 x 100W @ 100 volts 6W standby Flexible mounting options including mounting 6 x BS170S in a 3U rack space using the optional RM160 rack mount tray.

Technical information

SPECIFICATIONS
Supported file formats
MP3, AAC, WMA, OGG Vorbis, WMA-L, FLAC, ALAC, WAV, AIFF, MQA, HRA

Supported Cloud Services
SoundMachine, Tunify, Custom Channels, SiriusXM for Business, Spotify, Tidal, Amazon, Deezer, Qobuz, TuneIn, Radio.com, Qsic, and many others

Supported Operating Systems
Microsoft Windows 7 SP1 or later, Apple Macintosh OSX 10.7.5 or later

Free internet radio
TuneIn Radio, iHeartRadio, Calm Radio, Radio Paradise, Slacker Radio

partners for integration
Control4, RTI, Crestron, URC, ELAN, Lutron

rated capacity
2 x 80W at 4/8 ohms
2 x 100 W at 70 volts
1 x 100W at 100 volts

nominal distortion
=0.005%

signal to noise ratio
-110dBA

sampling rate
32 - 192kHz

bit depth
16 - 24

ENTRANCE
Analogous
Phoenix

USB
Type A (for USB memory stick and supported peripherals - FAT32 formatted)
Type B Mini USB (for maintenance purposes only)

IR input
Phoenix

OUTPUT
Subwoofer OUT
Phoenix

Loudspeaker OUT
Phoenix speaker terminal block

NETWORK

Gigabit Ethernet RJ45

user interface
FREE Android and iOS app available on GooglePlay and the Apple App Store

GENERAL SPECIFICATIONS
AC power adapter
AC power adapter

standby power
6W (networked standby mode)

Dimensions (W x H x D)
70 x 120 x 350mm (2.81 x 4.75 x 13.81')

net weight
1.6kg (3.5lb)

shipping weight
2.3kg (5.1lb)

RM 160 RACK MOUNT ACCESSORIES
Dimensions (W x H x D)
480 x 135 x 460mm (18.9 x 2.3 x 18.1')

Weight
4.28kg (9.45lb)
