Productnumber
274006
The completely digital signal path up to the loudspeaker output enables an absolutely high-quality signal flow in the pre-amplification without phase shifts, noise or distortion. The 35 bit signal processing as well as the use of a 108 MHz master clock guarantee the implementation of the highest quality in the context of the current digital technology. With barely measurable distortion and noise values, the C 390DD delivers 160 W minimum power per channel, whereby the automatic impedance adaptation of the Digital Power Drive circuit to the connected loudspeakers ensures optimum performance. If necessary, the Digital Power Drive technology can also dynamically triple the output without any loss of sound. The C 390DD is also equipped with a Room EQ, which enables precise corrections to be made in order to improve the sound in the listening room. In addition to two optical inputs, one optical output, two coaxial inputs, one coaxial output and an AES / EBU input, the C 390DD has an asynchronous USB port that enables music playback from the computer with a resolution of 24 bit / 96 kHz. There are also additional USB interfaces on the front and back for connecting USB memory sticks and / or hard drives.
Digital input (coaxial, optical) |
Input impedance | 75 ohms (coaxial) 110 ohms (AES / EBU) |
sampling rate | 32 kHz to 192 kHz |
Frequency response | ± 0.5 dB (Ref. 20 Hz - 96 kHz @ 192 kHz) |
Channel separation | > 90 dB (Ref. 10 kHz, 4 Ohm 1/3 power) |
Performance data |
Minimum continuous performance on 4 and 8O | = 160 W |
THD | <0.003% (Ref. 20 Hz-20 kHz, 500 mW) |
Clipping power | > 165 W (Ref. 1 kHz, 8 Ohm, 0.1% THD) |
IHF dynamic performance | 195 W at 8 ohms 350 W at 4 ohms |
Maximum output current | > 18 A |
Signal-to-noise ratio | > 95 dB (A-weighted Ref. 1 W) > 124 dB (A-weighted Ref. 250 W) |
Damping factor | > 800 (Ref. 20 Hz-200 Hz) |
General data |
Consumption in standby | <0.5 W |
Dimensions gross | 435 x 132 x 388 mm |
Net weight | 7.7 kg |
Packing weight | 9.78 kg |
| Color: |
graphite |
| Condition: |
new item |
| Product type: |
amplifier |
Product number
274006
The completely digital signal path up to the loudspeaker output enables an absolutely high-quality signal flow in the pre-amplification without phase shifts, noise or distortion. The 35 bit signal processing as well as the use of a 108 MHz master clock guarantee the implementation of the highest quality in the context of the current digital technology. With barely measurable distortion and noise values, the C 390DD delivers 160 W minimum power per channel, whereby the automatic impedance adaptation of the Digital Power Drive circuit to the connected loudspeakers ensures optimum performance. If necessary, the Digital Power Drive technology can also dynamically triple the output without any loss of sound. The C 390DD is also equipped with a Room EQ, which enables precise corrections to be made in order to improve the sound in the listening room. In addition to two optical inputs, one optical output, two coaxial inputs, one coaxial output and an AES / EBU input, the C 390DD has an asynchronous USB port that enables music playback from the computer with a resolution of 24 bit / 96 kHz. There are also additional USB interfaces on the front and back for connecting USB memory sticks and / or hard drives.
Digital input (coaxial, optical) |
Input impedance | 75 ohms (coaxial) 110 ohms (AES / EBU) |
sampling rate | 32 kHz to 192 kHz |
Frequency response | ± 0.5 dB (Ref. 20 Hz - 96 kHz @ 192 kHz) |
Channel separation | > 90 dB (Ref. 10 kHz, 4 Ohm 1/3 power) |
Performance data |
Minimum continuous performance on 4 and 8O | = 160 W |
THD | <0.003% (Ref. 20 Hz-20 kHz, 500 mW) |
Clipping power | > 165 W (Ref. 1 kHz, 8 Ohm, 0.1% THD) |
IHF dynamic performance | 195 W at 8 ohms 350 W at 4 ohms |
Maximum output current | > 18 A |
Signal-to-noise ratio | > 95 dB (A-weighted Ref. 1 W) > 124 dB (A-weighted Ref. 250 W) |
Damping factor | > 800 (Ref. 20 Hz-200 Hz) |
General data |
Consumption in standby | <0.5 W |
Dimensions gross | 435 x 132 x 388 mm |
Net weight | 7.7 kg |
Packing weight | 9.78 kg |
