Sonance Sonamp DSP 2-150 MKIII 2-Channel amplifier 19Inch DSP

Sonance Sonamp DSP 2-150 MK III 2-Channel Amplifier

High-end amplifiers for outstanding sound

Experience ultimate sound quality with the SONAMP DSP 2-150 Mk III power amplifier. This technical masterpiece features two analog inputs with automatic priority switching and two analog loop outputs, enabling flexible signal processing. An optional DIM module allows for the integration of digital inputs and effortless mixing of the input signal from stereo to mono.

The intuitive SonArc web interface allows for comprehensive configuration and provides access to 10 parametric equalizers per channel. A wide range of pre-configured DSP presets for Sonance and James loudspeakers are available for optimal adaptation to different speaker types. Key functions can be easily controlled via IP or IR commands from third-party devices, while automatic signal detection or master trigger activates the power amplifier. With a trigger voltage of 3 to 30 volts, compatibility with a wide range of devices, including Bang & Olufsen, is ensured.

Technical specifications and outstanding performance of the Sonamp DSP 2-150 MK III

Despite its compact design in a half-rack 1U chassis, the DSP 2-150 Mk III delivers an impressive 224 watts per channel at 4 ohms in simultaneous operation. The universal crossover in these stereo power amplifiers allows for active operation of even subwoofer-satellite combinations or high-quality multi-way loudspeakers. The space-saving design of this amplifier series requires up to 68% less rack space.

Innovative technology for optimal sound environment

The SONARC (Sonance Advanced Room Correction) technology in Sonance DSP amplifiers offers hundreds of equalizer presets specifically optimized for Sonance loudspeakers. No additional hardware or software is required for installation and fine-tuning of the sound system. The integrated 10-band equalizer provides further customization options, allowing specialist dealers to precisely measure and optimize the sound.

Additional control options

• Crestron, Savant and Control4 drivers: Available drivers enable seamless integration into modern home automation systems.
• IR-Control: Infrared control commands for easy operation.
• IP-Control: Network control for enhanced control and flexibility.

With the SONAMP DSP 2-150 Mk III you will not only experience first-class sound quality, but also outstanding efficiency and flexibility that takes your audio experience to a new level.

Technical specifications of the Sonamp DSP 2-150 MK III

• Product : 2-channel amplifier, DSP/EQ amplifier
• Manufacturer : Sonance

Channels and performance

• Channels : 2
• Power output at 8 ohms RMS : 150 watts
• Power output at 4 ohms RMS : 224 watts
• Mono bridged power output : 473 watts

functions

• EQ : Yes
• DSP : Yes
• Subsonic filter : Yes

Connections and control

• Ethernet/RS-232 : Yes
• Autosensing : Yes
• Trigger In : Yes
• Trigger Out : Yes
• Priority 2nd entrance : Yes

Physical properties

• Width : 219 mm
• Height : 44 mm
• Depth : 427 mm
• Weight : 5 kg
• Height units (HU) : 1

Miscellaneous

• Groundlift : No

This list provides a concise summary of the most important information and gives a good overview of the amplifier's features and technical specifications.
