T+A R1520 Stereo-Receiver

This device is a used device and is in good condition.

The T+AR 1520 R is a powerful high-end stereo receiver that meets the highest standards of sound quality, flexibility, and craftsmanship. As part of T+A's renowned R series, the R 1520 R combines the outstanding amplifier technology of the PA 1520 R with a high-quality integrated FM tuner and extensive connectivity options. The result is a device that is ideally suited for both classic hi-fi setups and modern multi-room or high-resolution systems.

The amplifier section of the R 1520 R delivers a nominal power of 180 W per channel into 8 O speakers and impresses with extremely low distortion (<0.001%), a high damping factor (>500), and a signal-to-noise ratio of over 110 dB. This allows even complex speaker loads to be effortlessly controlled, and even the finest details in music recordings are reproduced clearly and dynamically. The bandwidth extends from 1 Hz to 300 kHz, ensuring impressive linearity and precision across the entire audible range.

The integrated FM tuner allows reception of classic FM stations and features RDS display and an MPX filter to prevent interference. With high sensitivity for mono and stereo signals and a headroom of over 110 dB, the tuner ensures interference-free reception and precise station playback.

In addition to its excellent amplifier and tuner performance, the R 1520 R offers a wide range of connections, including balanced XLR inputs, unbalanced RCA inputs, tape and CD inputs, and a phono input for MM and MC cartridges. This allows for flexible integration into existing hi-fi systems or combination with external devices such as SACD players, streamers, or turntables. The R-Link interface also supports connection to other T+A devices for advanced control and synchronization.

The R 1520 R's cabinet is precision-crafted to minimize vibrations, combining visual elegance with high stability. Measuring 15 cm high, 44 cm wide, and 39 cm deep, the receiver fits easily into standard hi-fi racks, and its weight of 18.5 kg underscores its high-quality, robust construction. The receiver is available in black, silver, and optionally chrome and can be conveniently controlled with an optional remote control.

Technical data

• Type: Stereo receiver with integrated tuner
• Rated power: 180 W per channel at 8 Ohms
• Frequency range: 1 Hz – 300 kHz
• Frequency response: +0 – 3 dB at 0.5 Hz – 350 kHz
• Slew rate: 60 V/µs (stereo), 120 V/µs (mono)
• Damping factor: > 500
• Signal-to-noise ratio (A-weighted): > 110 dB
• Total harmonic distortion: < 0.001%
• Reception range: FM 87.5 – 108 MHz
• Sensitivity Mono (S/N = 26 dB): 0.9 µV
• Stereo sensitivity (S/N = 46 dB): 28 µV
• Overhead margin: > 110 dB
• MPX filter: 19 kHz + 38 kHz
• RDS display: station name
• 2 x speaker connections (A + B)
• 1 x XLR input (balanced)
• 1 x RCA input (unbalanced)
• 1 x Tape 1/2 input
• 1 x CD input
• 1 x tuner input
• 1 x TV input
• 1 x Phono input (MM/MC)
• 1 x R-Link interface
• Dimensions: Height: 15 cm, Width: 44 cm, Depth: 39 cm
• Weight: 18.5 kg
• Colors: Black (RAL 9005), Silver, Chrome (special version)
• Remote control: Optionally available

Special features

• High-quality amplifier technology based on the PA 1520 R
• Integrated FM tuner with RDS function and MPX filter
• Phono input for MM and MC cartridges
• Balanced and unbalanced inputs for maximum flexibility
• R-Link interface for advanced device integration
• Precise workmanship and low-vibration construction for best sound quality

The T+AR 1520 R is the perfect choice for audiophiles seeking a powerful, versatile, and sonically outstanding receiver. With its combination of high-quality amplifier technology, integrated tuner, and flexible connectivity options, it offers a long-lasting, sophisticated listening experience that perfectly complements both classic and modern hi-fi systems.
