Nexo P10 Speaker Touring Version
€2,560.00
per Piece incl. VAT / incl. Shipping
Available in 10 weeks
GermanyWe ship your goods quickly and safely with DHL. After shipping you will receive a tracking number for package tracking.
Nexo P10 speaker
touring version
note note:
Please remember that a controller is required for optimal use of the speakers and subwoofers. Without a controller, the Nexo guarantee is also void. Please ask when purchasing.
P10
Speakon connectors are located on the side handles and rear connector panel (Touring version only). The installation version has a 2-pin cable for the audio signal to meet the IP54 protection class. The P10 is basically passive.
Key features
- Compact, unobtrusive, rounded body
- 10' neodymium bass driver and tweeter with 1.7' cone in a coaxial arrangement
- Variable HF radiation characteristics
- 136 dB SPL peak level
- Threaded inserts on rear and both sides for mounting mounting accessories
- Tripod mounts on both sides
- 4 x NL4, 4-pin assigned connectors; 2 on the back and 1 on each side
Specs
With NEXO processing
Frequency range (+6 dB) 63 Hz - 20 kHz
SPL peak level (1 m) 136 dB peak
Operating voltage 50 Vrms (150 Vpeak)
HF coverage angle (according to horn) 100° x 100° (standard) – 110° x 60° (with optional horn 110° x 60°)
Crossover frequency 63 Hz, 85 Hz
Nominal impedance 8O
features
Components 1 x 10' long throw 8 ohm neodymium coaxial woofer & 1.7' 8 ohm neodymium tweeter
Number of ways 2-way passive
Connectors (Touring version) 4 x NL4, 4-pin sockets (1 per handle + 2 on rear)
Connections (installation version) 1 x grommet with 2-core cable
Flying points 1 x universal mount on each side + 1 x on the bottom
Material Custom-made bent plywood from Baltic birch and poplar
Surface Black or white textured paint
Front (Touring version) Magnelis® steel grille and fabric backing
Front (installation version) UV-resistant acoustic fabric covering
Height x width x depth 497mm x 384mm x 274mm
Weight: net 15 kg
Operating temperature range 0°C - 40°C
Storage temperature range -20°C - 60°C
| Color: | black |
|---|---|
| Condition: | new item |
| Configuration: | Touring version |
| Device depth mm: | 274 |
| Device height mm: | 497 |
| Device width mm: | 384 |
| Features / special features: | Touring version |
| Product type: | compact loudspeaker |
Safety Information
Product-specific safety instructions can be found in the operating manual.
