Integra DRX 3.4 AV Receiver

Integra DRX-3.4 – 9.2-channel AV receiver for home cinema and multiroom

The Integra DRX-3.4 combines powerful amplification, state-of-the-art video and audio technologies, and professional integration options in a compact and elegant design. With 9.2-channel surround sound and support for Dolby Atmos® and DTS:X®, it delivers an impressive, three-dimensional soundscape for home theater, music, and gaming.

The integrated DIRAC Live room correction ensures precise acoustic adaptation to any listening environment and guarantees balanced, detailed sound reproduction. Additionally, the Dolby Atmos Height Virtualizer enhances the spatial effect, even without additional height or surround speakers. Thanks to AccuReflex™ phase adjustment, Atmos-enabled speakers are optimally aligned.

8K HDR and HDMI 2.1 support ensures the highest picture quality for movies, TV shows, and games. With HDR10+, Dolby Vision™, HLG, VRR, ALLM, and DSC, all content remains crystal clear and smooth. An eARC output allows for lossless transmission of high-resolution audio signals to compatible displays.

The DRX-3.4 is ideally equipped for multiroom and network functions. Wi-Fi (802.11ac), Ethernet, AirPlay 2, Chromecast built-in, DTS Play-Fi®, Works with Sonos, Spotify, TIDAL, Amazon Music HD and Roon-certified Hi-Res Audio playback make streaming music convenient and flexible throughout the house.

Professional installers benefit from extensive CI features: Web setup, HDMI diagnostics, RS-232, programmable 12V triggers, remote control and monitoring options (OVRC Pro, Domotz) and an optional rack mounting kit ensure clean and efficient installations.

The robust housing with its aluminum front panel and high-quality controls complete the premium package. The Integra DRX-3.4 impresses with uncompromising sound quality, modern video performance, and versatile integration options.

Technical specifications – Integra DRX-3.4

amplifier

9.2-channel AV receiver

100 W/Ch (8 O, 20 Hz–20 kHz, 0.08 % THD, 2-channel operation)

Dynamic power output: 250 W (3 O front), 220 W (4 O front), 130 W (8 O front)

IMAX® Enhanced certified

4–16 O Speaker compatibility

Precision DAC for 192 kHz / 24-bit multi-channel conversion

VLSC™ filter technology front L/R

Bi-amping Front L/R

Independent bass and treble control

Audio & Video

Dolby Atmos® and DTS:X® (5.2.4 / 7.2.2)

Dolby Atmos Height Virtualizer, Dolby Surround®, DTS Neural:X

HDMI 1-6: 8K/60, 4K/120, HDR10+, Dolby Vision™, HLG, BT.2020, VRR, ALLM, DSC, QFT, QMS

eARC, DeepColor™, xvColor™, LipSync, HDCP 2.3

Network & Streaming

Wi-Fi 802.11ac, Ethernet

AirPlay 2, Chromecast built-in, DTS Play-Fi®

Amazon Music HD, Spotify, TIDAL, TuneIn, Pandora, Deezer

Works with Sonos, multi-room support

Roon Tested, Hi-Res Audio (DSD, FLAC, WAV, ALAC, AIFF up to 192 kHz/24-bit)

Connections

7 HDMI inputs (1 front), Main Out (eARC), Sub/Zone 2 Out

2 digital audio inputs (1 optical, 1 coaxial)

7 analog audio inputs (6 rear, 1 front)

Zone 2 & Zone 3 preamplifier outputs

Phono input with MM equalizer

USB audio input (5V/1A)

Composite/Component Video, Headphone jack (6.3 mm)

9 gold-plated speaker connectors (banana plugs)

Ethernet LAN

Generally

Dimensions: 435 × 174 × 376.5 mm

Weight: 11 kg

Power supply: AC 120 V~, 60 Hz

Power consumption: 750 W, Standby: 0.1 W

FM/AM tuner with 40 memory presets
