ZigBee Extender 3—ZCA-ZXT30

With Control4's ZigBee Extender 3, it's possible to create a powerful and expansive ZigBee mesh network that offers greater range and greater stability than ever before. Control4's ZigBee PRO™ mesh networking technology delivers industry-leading functionality, stability and scalability, providing significant benefits for both end users and installers. However, as with many wireless communication solutions, there are always unforeseen challenges to overcome. That's why Control4 dealers have relied on these products for nearly eight years to help overcome these challenges and optimize mesh network performance.

The ZigBee Extender 3 is specifically designed to achieve a single goal: extend and amplify the ZigBee mesh. No other product on the market provides this functionality as effectively as the Control4 ZigBee Extender.

This extender can be used in various projects to:

• Dealing with parent-child device relationships and routing or non-routing nodes.
• to eliminate “dead zones” in the mesh network.
• Significantly increase the size and density of the ZigBee mesh network.
• To reduce the latency of ZigBee signals at the edges of a mesh network.

The advanced features of the ZigBee Extender 3 offer an even more powerful solution:

• Larger routing tables. The routing table in the ZigBee Extender 3 is over eight times larger than previous models and supports up to 64 nodes – twice as many as other available extenders.
• Easy installation: With Control4's easy-to-use one-button setup method, the extender is quickly ready to use in just four clicks.
• Range of up to 900 feet (with clear line of sight from the Control4 controller).

Technical data

System requirements for Control4

• Control4 Composer Pro 2.0 or higher

scope of delivery

• A ZigBee Extender 3
• A 5VDC power supply for North America
• A Velcro™ strip for wall mounting

power source

• 5VDC at least 200mA power

communication

• ZigBee (IEEE 802.15.4) 2.4 GHz, 15-channel spectrum radio

environmental conditions

• Humidity : 5% to 95%, non-condensing
• Storage temperature : -20°F to 158°F (-28°C to 70°C)
• Operating temperature : -20°F to 158°F (-28°C to 70°C)

Miscellaneous

• Dimensions : 2.80 × 1.75 × 0.57 in (77 × 45 × 14 mm)
• Weight : 1.6 ounces (45 g) with batteries
• Regulation : CE, FCC Part 15 Class B, RoHS compliant
