Ortofon 2M Mono Tone pickup
€399.00
per Piece incl. VAT / incl. Shipping
Available, delivery time: 1-3 days
GermanyWe ship your goods quickly and safely with DHL. After shipping you will receive a tracking number for package tracking.
Pickup Type: | MM (moving magnet) |
Output voltage: | 4.0mV * |
Amplifier connection: | Phono MM |
Frequency range: | 20-22,000Hz |
Frequency response: | 20-20,000Hz + 3 / -1dB |
Sampling ability at 315Hz: | 70 µm ** |
Compliance: | 18 µm / mN |
recommended Tonearm type: | easy and medium difficulty |
Scanning diamond: | elliptical, naked |
Rounding: | r / R 8/18 µm |
Tracking force range: | 16-20mN (1.6-2.0g) |
recommended Tracking force: | 18mN (1.8g) |
Scanning angle: | 20 degrees |
DC resistance: | 700 ohms |
Inductance: | 350mH |
recommended Terminating resistor: | 47kOhm |
recommended Termination Capacity: | 150-300pF |
Housing material: | Noryl / glass composite |
Weight: | 7.2g |
Specialty: | Mono generator, |
for mono vinyl records with micro groove grooves (from approx. 1950) | |
Replacement needle insert: | Stylus 2M Mono |
| Condition: | new item |
|---|---|
| Configuration: | standard version |
| Product type: | Pickup MM |
Manufacturer
Ortofon A/S
Stavangervej 9
DK-4900 Nakskov
Denmark
support@ortofon.dk
Safety Information
Download file attachment
