Ortofon 2MR 78 Cartridge
€149.00
per Piece incl. VAT / incl. Shipping
Available, delivery time: 1-3 days
GermanyWe ship your goods quickly and safely with DHL. After shipping you will receive a tracking number for package tracking.
2MR 78 pickup
The 2MR 78 is a top-class scanner that features improved technology that enables excellent tonal accuracy. What's special about this stylus is the use of a spherical diamond tip, which is perfect for playing 78 rpm shellac records and has a larger stylus profile. The cartridge construction is made of Hopelex, which ensures high rigidity and eliminates unwanted resonances.
A special feature of the 2MR 78 is the use of a strapped output, which delivers the same output signal from both pole pins. This effectively eliminates the need for mono-specific equipment and allows true mono playback to be enjoyed on any stereo playback system.
The 2MR series is characterized by its excellent compatibility and can be used in various playback systems and with a variety of phono preamplifiers.
Technical data:
- Output voltage at 1000 Hz, 5 cm/s: 4 mV
- Frequency response: 20-20,000 Hz (+3 / -1 dB)
- Scanning capability at 315 Hz with recommended tracking force: 70 µm
- Dynamic lateral compliance: 18 µm/mN
- Stylus Type: Spherical
- Stylus tip radius: 65 µm
- Recommended contact pressure: 1.8 g (18 mN)
- Internal resistance (DC resistance): 700 ohms
- Inner coil: 350 mH
- Recommended load resistance: 47 kOhm
- Recommended load capacity: 150-300 pF
- Scanning angle: 20°
- Cartridge color (body/stylus): Black/Grey
- Weight of the 2MR 78 cartridge: 6 g
- Weight of the 2MR and 2M Verso cartridges: 7.2 g
- Weight of the pre-installed 2MR cartridge: 16.7 g
Stylus lifespan: With proper care, a lifespan of up to 1000 hours can be achieved without loss of performance. Please read more about stylus care in our FAQs.
Interchangeability of the 2M Series: The motors, coils and magnet configurations of the 2M Series are not identical. The 2M Red and 2M Blue are identical, as are the 2M Bronze and 2M Black, and the true mono variants 2M Mono and 2M 78. Likewise, the 2M Series Stylus are interchangeable within the following combinations:
- 2M Red, 2M Blue and 2M Silver
- 2M Bronze and 2M Black
- 2M Mono and 2M 78
With the 2MR 78 you get a scanner that offers the highest sound quality, compatibility and durability. Discover the fascination of playing shellac records in the best possible quality and enjoy your music collection on a completely new level.
| Abschlussimpedanz in Ohm: | 47000 |
|---|---|
| Cartridge type: | MM |
| Condition: | new item |
| Configuration: | standard version |
| Output voltage in mV: | 4 |
| Product type: | Pickup MM |
| Series: | 2MR |
| Tracking force in g: | 1.60-2.0 |
Manufacturer
Ortofon A/S
Stavangervej 9
DK-4900 Nakskov
Denmark
