Clearaudio SMART PHONO Headphone V2
€800.00
per Piece incl. VAT / incl. Shipping
Available, delivery time: 1-3 days
GermanyWe ship your goods quickly and safely with DHL. After shipping you will receive a tracking number for package tracking.
A minimalist aluminum housing contains one of the most powerful phono preamplifiers on the world market: Up to 54 decibels of amplification at one kilohertz and an extremely linear frequency response are superlatives that the entry-level class has never seen before.
Two separate circuit designs in SMD technology are available for MM and MC, which can be selected using a slide switch on the underside of the device.
In its solid aluminum housing, the Smart Phono Headphone V2 also has a powerful headphone output for undisturbed listening pleasure at the highest level.
GAIN @ 1 KHZ | 54 - 68 dB (MC operation) |
INPUT IMPEDANCE | 50 ohms, 100 ohms, 500 ohms, 1 kOhm, 5 kOhm / 150 pF, 250 pF, 400 pF (MC operation) |
MM / MC - INPUT | switchable (on the bottom) |
RUBBER FILTER | switchable (on the bottom) |
CUTTING CHARACTERISTICS EQUALIZATION | According to RIAA (time const .: 75 µs / 318 µs / 3180 µs) |
RIAA ACCURACY | ± 0.3 dB @ 10 Hz - 100 kHz |
CLONE FACTOR | <0.004% MC ('A' weighted @ 1 kHz / -1 dB @ Max) |
OVERRIDE RESISTANCE | 18 dB / MC (Gain Control on MAX) |
SIGNAL / NOISE RATIO | 72 dB / MC ('A' Weighted) |
CROSS-TALK ATTENUATION | > 90 dB @ 1 kHz / opposite channel short-circuited |
MAX. OUTPUT VOLTAGE | 10 V eff. (1 kHz) |
POWER SUPPLY | ± 18 V DC / 300 mA (external plug-in power supply, plastic housing) |
EXITS | asymmetrical (CINCH) |
POWER CONSUMPTION | Max. Power consumption: 2.7 watts |
WEIGHT | approx. 600 g (preamplifier and power supply) |
DIMENSIONS (W / D / H in inches) | 3.74 x 4.92 x 1.34 |
DIMENSIONS (W / D / H in mm) | 95 x 125 x 34 |
| Color: | black |
|---|---|
| Condition: | new item |
| Product type: | Phono preamplifier |
Manufacturer
clearaudio electronic GmbH
Spardorfer Strasse 150
91054 Erlangen
Deutschland
info@clearaudio.de
Safety Information
Product-specific safety instructions can be found in the operating manual.
