Trine VANGUARD II
Phono amplifier for MM and MC systems. Externally accessible switches enable optimal adjustment of amplification, resistance and capacity to a wide variety of pickup systems. The outsourced power supply allows the Vanguard to be set up directly next to the turntable. - A small in price - with great sound performance and just such equipment and processing.
Technical specifications
| reinforcement | 42 – 66 dB adjustable in 16 steps |
| input resistance | from 25 ohms to 1800 ohms in 31 steps |
| without connected resistors 47KOhm | |
| capacity | Basic capacitance = 60 – 100pF |
| switchable capacity = 47pF, 100pF, 147pF | |
| Entry | 1x RCA |
| Exit | 1x RCA |
| signal-to-noise ratio | -72dB at 60dB gain and |
| -94dB at 36dB gain | |
| frequency response | +- 0.2 dB RIAA equalized |
| Distortion THD + N | 0.06% |
| crosstalk attenuation | -96.2dBA at 10KHz |
| power consumption | <3VA |
| Dimensions H x W x D | 58.5mm x 200mm x 320mm |
| Color: | black - textured paint black |
|---|---|
| Condition: | new item |
| Device depth mm: | 320 |
| Device height mm: | 58.5 |
| Device width mm: | 200 |
| Inputs: | Analog RCA |
| Material: | aluminum |
| Outputs: | Analog RCA |
| Product type: | Phono preamplifier |
| Series: | Vanguard II |
