AVM R 30.3 Turntable

AVM ROTATION R 30.3 + CLEARAUDIO PERFORMER V2 MM

AVM ROTATION R 30.3

Turntable with single motor belt drive

9'' AVM tonearm gimballed

Massive 35 mm HDF composite frame, painted and reinforced with polished aluminum front (identical to the R 2.3)

Mass drive on four height-adjustable damper feet

Blue turntable lighting (dimmable & switchable)

Hinged cover made of acrylic glass

33/45 RPM with look-forward servo control

Pre-assembly desired?

This AVM R30.3 comes with a Clearaudio Performer V2 MM pickup. The pickup is not pre-assembled. Would you like the pickup pre-assembled? Just let us know by email or as a comment in the shopping cart.

The ROTATION R 30.3 at a glance

The AVM R 30.3 is the youngest member of the AVM turntable family and offers a perfect analogue addition to the AVM 30 line of devices introduced as part of the 30th AVM company anniversary. The typical AVM design language has been elegantly incorporated and so the device is suitable not only for supplementing existing AVM systems but also as an entry into the AVM analogue world.

The success story started at High End 2018 with the introduction of two AVM turntables:

The top model, the ROTATION R 5.3, sets numerous technical and innovative accents in terms of the drive. The complex elipso-centric belt drive is an example. It achieves a completely unloaded platter axis with a tilting moment of 0.0. Not only the spring-loaded drive, but especially the 10'' tonearm developed by AVM made of highly polished aluminum components are acoustic, technological and aesthetic delicacies of the R 5.3.

The R 2.3 appeared at the same time as the R 5.3. This now serves as a direct source of ideas for the development of the new AVM R 30.3. Based on the design features of the R 2.3, the R 30.3 adopts several clear borrowings. The highlight of the R 30.3 is the identically adopted 9'' tonearm with its sophisticated detailed solutions. This tonearm is a completely proprietary AVM construction. It effortlessly carries all well-known pick-up systems on the world market. It is also possible to mount your own, high-quality AVM Cadenza pickups and this shows the full potential of the tonearm.

The stable, ultra low mass tonearm is based on a solid, refined aluminum tube. In combination with the stable and precise tonearm bearing, it offers the basis for a powerful sound. The silicone-damped counterweight effectively prevents the reflection of micro-vibrations in the direction of the tonearm and the pickup system, thus guaranteeing a pure, clearly defined sound image.

All Rotation turntable models have frames made of heavy composite material (in different thicknesses) in common. These frames are made of cement-powdered HDF, glued to hand-polished anodized aluminum parts and thus additionally reinforced. The use of different materials creates a vibration-damping sandwich structure that offers an almost completely resonance-free, solid substructure for the matt and internally illuminated acrylic turntable. The precise upside-down bearings are other precision parts that are primarily responsible for the remarkably smooth running of the R 30.3. An intelligent, fully electronic look-forward servo control allows the turntable to rotate precisely and constantly.

details

finish
Aluminum Silver, Aluminum Black

product weight
9kg

Effective tonearm length
230mm

overhang
18mm

speed variance
33rpm: ±0.15% max, 45rpm: ±0.13% max

wow and flutter
33rpm: ±0.12% max, 45rpm: ±0.10% max

signal-to-noise ratio
-70dB

downforce range
0-35mN, 0-3.5g

Supplied counterweight
For pickups from 6 - 14 g

product dimensions
350 x 462 x 155 mm (D x W x H)

power consumption
15VDC/1.6A (100-240VAC, 47-63Hz)

mounting clearance
212 mm (platter – tonearm base, Linn standard mount)

Effective tonearm mass
13.5g

Clearaudio Performer V2 MM

The moving magnet pickups are repeatedly measured, analyzed and hand-selected on four levels. In this way, clearaudio achieves perfect homogeneity of the stereo channels and minimal phase or transient distortion. With a linear frequency response and high output voltage, this creates an audiophile sound of superlatives - spatial, rich in detail, multicolored and at the same time homogeneous and profound; with basses that don't boom and trebles that lack any sharpness.
The models of the clearaudio MM-V2 series convince in terms of sound on all common tonearms.
Except for the concept MM V2, which is made of aluminium, the socket of all pickups in this series is made of hand-polished ebony. As a result, record-breaking values are also achieved in terms of weight.

Technical specifications

• transmission bandwidth
  23Hz - 20kHz
• output voltage
  3.6mV
• Channel separation (1kHz)
  > 26dB
• Channel balance (1kHz)
  < 0.8dB
• scanning capability
  80 micro m
• Support weight (recommended 1.8-2.6g)
  2.0g
• Coil Impedance (1kHZ)
  0.66k ohms
• coil inductance
  0.40h
• load resistance
  47k ohms
• capacitive load
  100pF
• needle carrier
  aluminum
• Weight
  7.4g
