McIntosh MA5300 AC Black Edition with DA2-DAC-Modul

The McIntosh MA5300 AC Black Edition is impressive proof that uncompromising sound can be achieved even in a compact format. As the smallest integrated amplifier in the current McIntosh portfolio, it combines power, modern technology, and timeless design – now in a lavishly designed special version available exclusively for the German-speaking market. This makes it ideal for both discerning newcomers to the McIntosh world and connoisseurs seeking a powerful device for smaller rooms or secondary systems.

Limited special edition with collector value

The Black Edition gives the MA5300 AC a distinctive look. Instead of the typical side handles, black aluminum side panels dominate, combined with dark accents and the iconic glass front, which is completely black here. A visual highlight is the blue-illuminated VU meters, which provide an elegant contrast to the jet-black front.

Particularly exclusive: Each unit bears a hand-signed, numbered label from McIntosh President Charlie Randall. This personal signature makes each unit a true collector's item and lends the Black Edition not only technical but also emotional value.

Powerful integrated amplifier in a compact format

Despite its comparatively small dimensions, the MA5300 AC impresses with its impressive output power. The direct-coupled amplifier delivers

• 100 watts per channel at 8 ohms and
• 160 watts per channel at 4 ohms .

This allows it to effortlessly drive a wide range of demanding loudspeakers. The newly developed, dual-scale VU meters allow for precise display of the output power at both load impedances. McIntosh's signature Monogrammed Heatsinks™ technology ensures reliable cooling, combining functionality with iconic design.

DA2 instead of DA1 – future-proof digital platform

A key feature of the Black Edition is the DA2 Digital Audio Module , which is installed as standard. This distinguishes the special edition from the standard model, which was equipped with the DA1.

The DA2 is based on a 32-bit, 8-channel DAC in quad-balanced mode and supports the latest high-resolution audio formats. The seven digital inputs include:

• 2x coaxial
• 2x Optical
• 1x USB (up to 32 bit/384 kHz, DSD512, DXD384)
• 1x MCT (for McIntosh transport devices)
• 1x HDMI ARC for seamless integration into TV systems

This makes the MA5300 AC Black Edition optimally prepared for current and future digital sources – from high-res streaming to home cinema applications.

Analogue connection variety for maximum flexibility

The integrated amplifier also impresses with its diverse analog connection options. A total of six inputs are available:

• 1x balanced XLR input
• 4x unbalanced RCA inputs
• 1x Phono MM input for vinyl record lovers

This means that both classic players and modern source devices can be integrated.

Proven McIntosh features

In addition to the technical basis, the Black Edition offers the typical protection and comfort features of McIntosh:

• Power Guard® : monitors the signal in real time and protects against distortion and clipping.
• Sentry Monitor™ : Short circuit protection with automatic reset.
• Home Theater PassThru : enables easy integration into an existing home theater system.
• High Drive headphone amplifier with HXD® : provides a more spatial sound image through headphones.
• Gold-plated speaker connectors : resistant to corrosion and guarantees signal stability.

The MA5300 AC Black Edition combines security, flexibility and audiophile attention to detail.

Technical data at a glance

• Power: 2 x 100 watts at 8 ohms, 2 x 160 watts at 4 ohms
• Total harmonic distortion: 0.005%
• Frequency response: 20 Hz – 20 kHz (+0 / -0.5 dB); 10 Hz – 100 kHz (0 / -3 dB)
• Signal-to-noise ratio: High level 95 dB, Phono (MM) 82 dB, Power amplifier 110 dB
• Damping factor: > 200 (8 Ohm), > 100 (4 Ohm)
• Analogue inputs: 4x RCA, 1x XLR, 1x Phono MM
• Digital inputs: 2x Coax, 2x Optical, 1x USB, 1x MCT, 1x HDMI ARC
• Dimensions (W x H x D): 44.5 x 15.3 x 47.6 cm
• Weight: 17.2 kg (25.2 kg including packaging)

Design: Black. Elegant. Timeless.

With its all-black appearance, the Black Edition stands out clearly from the traditional McIntosh design without losing its brand identity. The blue VU meters add a strong visual accent, while the matte black side panels complete the look. The result is a timeless, elegant design that is equally impressive in both modern and classic living spaces.
