Rotel Michi X3 S2 Integrated Stereo Amplifier

X3 Series 2

The Michi X3 Series 2 integrated amplifier offers an unmatched, extraordinary listening experience with musical precision, delicacy and breathtaking detail. Digital audio signals are reproduced via a high-precision ESS SABER ES9028PRO 8-channel D/A converter configured with 4 dedicated channels for left and right audio channels to lower the noise floor, reduce distortion and build an impressive, wide stage.

With its elegant industrial design, the Michi X3 Series 2 blends harmoniously into any living environment and delivers a robust 350 watts from your favorite music sources including analogue RCA, optical, coaxial, PC-USB with MQA (24-bit, 384 kHz), PCM (32-bit , 384 kHz) and Quad DSD (11.2 MHz), XLR balanced and wireless aptX™ HD Bluetooth. Vinyl fans will appreciate the phono input for moving magnet systems. The Michi X3 Series 2 is designed for music lovers and audiophiles. All aspects of its design, engineering and manufacture have been carefully refined to achieve exceptional quality. The oversized toroidal transformer, manufactured in-house, independently powers the digital, analog and high-current amplifier circuits to further reduce noise and interference.

Operating and setting up the X3 Series 2 is particularly easy thanks to the included Michi IR remote control, front panel controls and large graphic display. The dual platinum plated speaker terminals allow bi-wiring as well as traditional speaker connection. For full listening pleasure without disturbing others, there is a full-size 1/4" headphone jack on the front panel. The RS232 and Ethernet sockets allow easy connection to automation and control systems.

Technical specifications

DIMENSIONS (W × H × D)

485x150x452mm
19' × 6' × 17 3/4'

PANEL HEIGHT

132mm (5.25')

POWER SUPPLY

230V, 50Hz

POWER CONSUMPTION

500W

STANDBY POWER CONSUMPTION

Normal: <0.5W

Network wakeup: <2W

NET WEIGHT

28.9kg (63.7lbs.)

BTU RATING

1303 BTU/hr

MAXIMUM POWER OUTPUT

350W/Ch (4O)

CONTINUOUS OUTPUT

200W/Ch (8O)

OVERALL THD

<0.008%

FREQUENCY RESPONSE

High level inputs: 10Hz - 100kHz (+0dB, -0.4dB)

Digital inputs: 20Hz - 20kHz (0 ± 0.4dB)

Phono input: 20Hz - 20kHz (+0dB, +0.4dB)

S/N RATIO (IHF 'A')

High level inputs: 102dB

Digital inputs: 102dB

Phono input: 80d
