Bowers & Wilkins CCM 683 Recessed loudspeaker round
€600.00
per Piece incl. VAT / incl. Shipping
Available, delivery time: 1-3 days
GermanyWe ship your goods quickly and safely with DHL. After shipping you will receive a tracking number for package tracking.
CCM 683 built-in loudspeaker
The CCM683 is equipped with many of the high-quality features of the CCM682, but the maximum recommended amplifier power is slightly lower at 130 watts. Like the CCM682, it features a 200mm Kevlar® fabric woofer with a rigid die-cast chassis and an aluminum dome tweeter based on NautilusÖ technology, which is adjustable to optimize high frequency response. It also has an EQ switch with three settings.
The paint finish of the CCM 683 is white, but can be painted as desired. The repainting is carried out by an external company and would be subject to a surcharge. Please contact us if you are interested.
Technical specifications
Description :
2-way speaker system ceiling
Frequency range :
-6dB at 35Hz - 50kHz
Sensitivity :
88dB SPL (2.83V, 1m)
Nominal Impedance :
8 ohms (minimum 4.5 ohms)
Recommended amplifier power :
25W - 130W
Size :
Diameter 290mm
Cut-out size :
Diameter 250mm
Min. depth required :
133 mm from ceiling surface
Equipment :
Pre-mount kit for new construction (PMK C8)
Back box (6C)
| Color: | white |
|---|---|
| Condition: | new item |
| Product type: | Built-in speakers |
