McIntosh CS200 In-Ceiling speaker

McIntosh CS200: Versatile in-ceiling loudspeaker for individual installations

The McIntosh CS200 In-Ceiling Loudspeaker is the ideal solution for customized audio installations, whether for distributed audio throughout the home or as a complement to a home theater system. Its versatility makes it an excellent choice for a wide range of applications, while its high-quality sound enhances any installation.

With a nominal output of 15 to 250 watts, the CS200 adapts flexibly to various amplifier systems. In combination with McIntosh amplifiers such as the MI128 or MI254, the loudspeaker unfolds its full potential and delivers a harmonious sound in distributed audio installations. Thanks to its coordination with the McIntosh WS500 and WS300 in-wall loudspeakers, the CS200 is also ideal for hybrid systems in which wall and ceiling loudspeakers work together.

Technical sophistication for impressive sound

The McIntosh CS200 is designed as a 3-way speaker and has a well thought-out driver configuration. The focus is on an 8-inch woofer made of woven glass fiber, which guarantees powerful and precise bass reproduction. This is supported by two 2-inch midrange drivers with inverted titanium domes and a 3/4-inch titanium tweeter. Together, these drivers ensure a balanced sound with impressive detail across all frequency ranges.

A special feature is the rotating array that houses the midrange and tweeter. This allows the sound to be directed precisely to the listening area, enabling optimal sound quality in any room. The drivers used come from the well-known McIntosh models XR50 and XR100, so the CS200 offers the same high standard as the brand's freestanding speakers.

Elegant design and easy integration

The design of the CS200 is not only functional but also aesthetically pleasing. The magnetically attached cover can be easily removed and, if required, individually adapted to the room design, as it can be painted. This means that the loudspeaker blends seamlessly into any environment and becomes almost invisible. With minimally visible edges of the mounting frame, the focus remains on the room design without the loudspeaker visually dominating.

The CS200 comes with all the necessary mounting mechanisms required for post-construction installation. For special requirements or new construction projects, an optional rough-in kit (#RK200) is available to make installation even easier.

Perfect for home theater and distributed audio

Whether as an in-ceiling speaker in a networked audio system or as a surround component in a home theater, the CS200 delivers reliable performance in every situation. Its tuned sound signature harmonizes perfectly with other McIntosh speakers and guarantees an immersive sound experience. Thanks to its wide frequency response from 48 Hz to 22 kHz and an efficiency of 89 dB, it is able to meet a wide range of requirements without compromising on sound quality.

Technical data of the McIntosh CS200

Electronic Specifications

• Impedance Nominal: 6 Ohm
• Power range: 15 to 250 watts
• Frequency response: 48 Hz to 22 kHz
• Sound pressure level (2.8 V/1 m): 89 dB
• Crossover frequencies: 1,100 Hz, 3,000 Hz

driver specifications

• Number of woofers: 1
• Woofer size: 8 inches
• Woofer Type: Woven Glass Fiber
• Number of midrange speakers: 2
• Midrange size: 2 inches
• Midrange type: Inverted titanium dome
• Number of tweeters: 1
• Tweeter size: 3/4 inch
• Tweeter type: titanium dome

General Specifications

• System type: 3-way ceiling speaker
• Cover: Magnetic metal grille, paintable
• Available finishes: Black housing with white cover
• Dimensions (W x H x D): 27.94 x 27.94 x 12.7 cm
• Weight: 2.49 kg
• Shipping weight: 3.18 kg

With the McIntosh CS200 you get a powerful and versatile ceiling speaker that can be perfectly integrated into various installations. Its high-quality workmanship and well thought-out features make it a worthwhile addition to any home theater or audio system.
