Ortofon SPU Synergy GM Cartridge
€2,199.00
per Piece incl. VAT / incl. Shipping
Available in 7 days, delivery time 1-3 days
GermanyWe ship your goods quickly and safely with DHL. After shipping you will receive a tracking number for package tracking.
Technical data:
Pickup type: MC (Low-Output Moving-Coil)
Tonearm mounting: SME connector
Output voltage: 0.5 mV*.
Amplifier connection: Phono MC
Channel deviation at 1 kHz: <1.5 dB
Crosstalk attenuation at 1 kHz: >23 dB
Crosstalk attenuation at 15 kHz: >15 dB
Frequency range: 20-30.000 Hz
Frequency response: 20-20,000 Hz ±2 dB
Scanning capability at 315 Hz: 70 µm**
Needle compliance: 8 µm/mN
Scanning diamond: elliptical, naked
Rounding: r/R 8/18 µm
Contact force range: 25-35 mN (2.5-3.5 g)
rec. contact force: 30 mN (3.0 g)
Scanning angle: 20 degrees
Direct current resistance: 2 Ohm
rec. terminating resistor: 10 - 50 Ohm
Case material: wood/resin
Weight: 30 g
*at 1000Hz, 5cm/sec **at recommended contact force
| Condition: | new item |
|---|---|
| Product type: | MC pickup |
Manufacturer
Ortofon A/S
Stavangervej 9
DK-4900 Nakskov
Denmark
