Pro-Ject Phono Box
€129.00
per Piece incl. VAT / incl. Shipping
Available, delivery time: 1-3 days
GermanyWe ship your goods quickly and safely with DHL. After shipping you will receive a tracking number for package tracking.
Newsletter
Subscription
Subscribe to our newsletter and receive a 10 EUR coupon code. Valid from an order value of 200 euros.
Subscribe
Consultation
Appointments
Our consultants will be happy to help you if you need product advice, a demonstration appointment in the auditorium of your choice or questions about our online shop.
+49 2381 / 9339-71 Contact Form262787 Pro-Ject Phono Box
Phono preamplifier (MM / MC)
Technology for good sound
Solid metal housing to protect the electronics from vibrations and interference
Double mono construction of the circuit for optimal channel separation
Outsourced power supply
Equipment features
Connection of MC and MM cartridges
Hard gold-plated RCA / Cinch sockets
Available with black and silver front panel
Technical specifications
Terminating resistor / terminating capacitance MM | 47 kOhm / 120pF |
Terminating resistor / terminating capacitance MC | 100 ohms / 12 pF |
Reinforcement, MM | 40 dB |
Output voltage, e.g. | 300 mV / 1kHz at 3mV at the MM input |
Reinforcement, MC | 60 dB |
Output voltage, e.g. | 300 mV / 1kHz at 0.3mV at the MC input |
S / N ratio, MM | 86 dB (94dB-IEC-A) |
Signal-to-noise ratio, MC | 68 dB (75dB-IEC-A) |
Harmonic distortion MM | <0.01% |
Harmonic distortion MC | <0.05% |
Accuracy of the RIAA equalization curve | Deviation max. 0.5 dB / 20Hz - 20 kHz |
Mains connection | Plug-in power supply, 18V / 500mA DC; 220-240V, 50Hz |
Power consumption | 80 mA DC |
Dimensions W x H x D (depth with sockets) | 103 x 36 x 104 (115) mm |
Weight | 570g without power supply |
| Color: | black |
|---|---|
| Condition: | New goods |
| Product type: | Phono preamplifier |
Phono preamplifier (MM / MC)
Technology for good sound
Solid metal housing to protect the electronics from vibrations and interference
Double mono construction of the circuit for optimal channel separation
Outsourced power supply
Equipment features
Connection of MC and MM cartridges
Hard gold-plated RCA / Cinch sockets
Available with black and silver front panel
Technical specifications
Terminating resistor / terminating capacitance MM | 47 kOhm / 120pF |
Terminating resistor / terminating capacitance MC | 100 ohms / 12 pF |
Reinforcement, MM | 40 dB |
Output voltage, e.g. | 300 mV / 1kHz at 3mV at the MM input |
Reinforcement, MC | 60 dB |
Output voltage, e.g. | 300 mV / 1kHz at 0.3mV at the MC input |
S / N ratio, MM | 86 dB (94dB-IEC-A) |
Signal-to-noise ratio, MC | 68 dB (75dB-IEC-A) |
Harmonic distortion MM | <0.01% |
Harmonic distortion MC | <0.05% |
Accuracy of the RIAA equalization curve | Deviation max. 0.5 dB / 20Hz - 20 kHz |
Mains connection | Plug-in power supply, 18V / 500mA DC; 220-240V, 50Hz |
Power consumption | 80 mA DC |
Dimensions W x H x D (depth with sockets) | 103 x 36 x 104 (115) mm |
Weight | 570g without power supply |
| Color: | black |
|---|---|
| Condition: | New goods |
| Product type: | Phono preamplifier |
Manufacturer
Audio Tuning Vertriebs GmbH
Wirtschaftspark A5 Mistelbach/Wilfersdorf
Analogweg 1
2130 Mistelbach AUSTRIA
[email protected]
Safety Information
Product-specific safety instructions can be found in the operating manual.
