Burmester 257 Turntable with external power supply

Burmester 257 record player

The new reference for analogue listening

Bringing music to life in its purest form is easy with the 257 turntable from Burmester.

As part of the new Reference Line, it embodies Burmester's uncompromising commitment to sonic perfection, innovative technology and timeless design.

Highlights at a glance

• Ultra-precise speed control for constant, interference-free music enjoyment
• Two-motor system with magnetically mounted plate for particularly quiet operation
• Completely redesigned structure – designed to the highest quality inside and out
• Modular expandable : with internal phono module or external solution
• Part of the new Reference Line – minimalist design, maximum sophistication

Analogue passion, redefined

The 257 combines outstanding engineering with sensitive material selection and state-of-the-art control technology. The result: an analog music experience that sets standards in precision, quietness, and naturalness.

Mechanical interference? Virtually eliminated. Thanks to a magnetically mounted platter, intelligent motor control, and optical speed control, the 257 performs at a level that will delight even the most discerning listeners.

Core technology with subtlety

• Optical Speed Control (OSC): With 1600 resolution steps, the sensor detects deviations in less than a millisecond – and corrects them immediately.
• Dual motor with belt drive: Two high-torque 12V DC motors drive precise flywheels – for whisper-quiet rotation.
• Hybrid control unit: A 12-bit DAC generates highly accurate reference voltages, and the analog motor unit automatically compensates for friction and temperature fluctuations.
• Magnetic bearing technology: The polished ceramic axle with bronze lining guarantees almost frictionless running.
• 50 mm sandwich turntable: Technical plastic meets stainless steel – for stability, freedom from vibration and quiet sound.

Design meets precision

The 257 is the first turntable in the new Reference Line design . Compact, minimalist, and elegant, it fits seamlessly into modern living spaces as well as sophisticated high-end systems.

Height-adjustable, with a central rotary switch and two buttons for the exact speed – the operation is as intuitive as the design is well thought out.

Modular and future-proof

An optional integrated phono module allows direct connection to line inputs. Alternatively, an external phono module or one of the Burmester amplifier modules can be used – for maximum flexibility in system design.

Technical data

• Synchronism : ± 0.05% at 33 or 45 rpm
• Power consumption :
  Maximum: 5.0W
  Average operating power: 2.1W
  Standby: < 1.0W
• Weight :
  Basic unit: approx. 25kg
  Power supply: approx. 17kg
• Dimensions (W × H × D) :
  Width: 450mm
  Height: 130mm (turntable) + 117mm (tonearm)
  Depth: 380mm

pickup

• Weight : 7.0g
• Frequency response : 20Hz – 20kHz
• Output voltage : 0.5mV at 5cm/s
• Channel separation : 25 – 30dB
• Channel deviation : < 0.5dB
• Scanning capability : 80µm
• Recommended tracking force : 2.8g (±?0.2g)
• Termination resistance : 50O
• Stylus (needle type) : Optimized Shibata, Prime Line
• Needle compliance : 15µm/mN
• Coil arrangement : Fully symmetrical design
• Coil material : 24 carat gold

tonearm

• Design principle : Radial tonearm with frictionless magnetic bearing
• Length : 9 inches (effective)
• Adjustment range pickup weight : 10g
• Overhang : 13.01mm
• Effective length : 308.01mm
• Mounting distance (tonearm pivot point to spindle) : 295.00mm
• Total length : 420.00mm
• Offset angle : 18.85°
