Clearaudio OVATION Drive Silver Chassis Black

Ovation with tonearm tracer and Jubilee MC cartridge

The Clearaudio Ovation turntable with tonearm Tracer and Jubilee MC cartridge is a true masterpiece of audio technology. With its precision-milled armored wood chassis and 100,000 incorporated metal balls, it creates an acoustic environment in which sound-damaging resonances have no chance. This exceptional chassis is embedded between two aluminum plates, which ensures optimal resonance damping.

Precision and stability

The Ovation is characterized by its solid 40 millimeter thick turntable, which is made of resonance-damping POM (polyoxymethylene). This plate ensures an exceptional running experience. Beneath the surface is a powerful, high-torque DC motor that runs extremely smoothly and is effectively decoupled.

Thanks to the Clearaudio Optical Speed Control (OSC) and the CMB ceramic magnetic bearing, the Ovation achieves synchronization values with minimal tolerances. This turntable sets a new standard in its class and enables an audiophile listening experience in a completely new dimension.

Award and technical data

The Ovation was named 'Turntable of the Year' by the trade magazine 'the Absolute Sound' due to its outstanding qualities. This is a recognition of his outstanding performance and precision.

Technical data of the Ovation turntable:

• Construction principle: Resonance-optimized drive, armored wood in sandwich construction embedded between two aluminum plates
• Speed range: 33?, 45, 78 rpm
• Drive: High-torque 24 volt DC motor, electronically controlled speed regulation (OSC) with optical sensor, drive with ground flat belt
• Bearing: Inverted, ground and polished ceramic bearing axle, sintered bronze bushing, including patented magnetic bearing technology (CMB)
• Platter: Solid 40mm platter made of high density engineering plastics with excellent dimensional stability, aluminum sub-platter
• Synchronization (weighted) less than ± 0.03%
• Power consumption: Max. power consumption: 8.6 watts, in operation: 2.5 watts, standby mode: 2.5 watts, switched off: 0.0 watts
• Weight: approx. 13.5 kg
• Dimensions (W/D/H): approx. 420 × 350 × 135 mm (without tonearm)

Tracer tonearm: precision and stability

The Tracer tonearm from Clearaudio is a radial tonearm that impresses with its precision workmanship and sound performance. It uses the best materials to ensure maximum stability with optimal agility. The extremely friction-free ball bearings and slanted tungsten axle ensure first-class performance.

The tonearm has a tonearm tube made of extremely torsion-resistant carbon, which offers maximum stability. The magnetic anti-skating is perfectly accessible and placed in the axis of rotation. The aluminum headshell with adjustable azimuth and the tonearm counterweight can be adjusted easily and precisely.

Technical data of the Tracer tonearm:

• Construction principle: Radial tonearm, horizontal sapphire bearing and vertical ball bearing
• Material: aluminum (black/silver), stainless steel, carbon tonearm tube (black/silver)
• Adjustable pickups: 3.5g - 17g
• Overhang: 17.12mm
• Total length: 320mm
• Effective length: 239.12mm
• Mounting distance (tonearm pivot point to spindle): 222 mm
• Offset angle: 25.00°
• Signal cable: 1.1 m Sixstream Super Wire assembled with MPC RCA
• Weight: 500g

Jubilee MC pickup: sound art made from armored wood

The Jubilee MC pickup from Clearaudio is the first moving coil pickup with a body made of armored wood. This unique material guarantees a high level of low resonance and minimal weight. The shape of the body is reminiscent of the masterpieces of the V2 series and demonstrates the highest level of craftsmanship.

Technical data of the Jubilee MC pickup:

• Mass of the entire system: 7.5 g
• Frequency response: 20Hz - 20kHz
• Output voltage (at 5 cm/sec): 0.5 mV
• Channel separation: > 32 dB
• Channel balance: <0.5dB
• Scanning ability: 80 µm
• Recommended support weight: 2.8 g (± 0.2 g)
• System impedance: 50 O
• Needle carrier / diamond cut: boron / Clearaudio Prime Line
• Needle flexibility: 15 µ/mN
• Coil arrangement: Absolutely pivot symmetrical
• Coil material: 24K gold
• System body: armored wood

The Clearaudio turntable Ovation with tonearm Tracer and Jubilee MC cartridge is the perfect combination of precision, material expertise and craftsmanship of sound. It offers an audiophile experience that will delight audiophile enthusiasts.

Ovation turntable configurations

The Ovation record player can of course be configured by us according to your wishes. Various tonearms, cartridges and drive versions are available. Please contact us and let us advise you.
