Trigon ADVANCE III Phonostage
€1,630.00
per Piece incl. VAT / incl. Shipping
Available, delivery time: 1-3 days
GermanyWe ship your goods quickly and safely with DHL. After shipping you will receive a tracking number for package tracking.
TRIGON ADVANCE
Phono amplifier for MM and MC systems with integrated battery power supply and external (charging) power supply unit. With the ADVANCE, pure battery power excludes acoustic network influences on the sensitive phono signals and enables true-to-life music reproduction freed from uncontrolled technical additions. - Enjoy the sonic progress.
The front-side switching and display of all operating states as well as software-controlled charge control and monitoring of the long-life lead-acid batteries ensure the simplest operation and maximum operational safety. Externally accessible switches enable the gain, resistance and capacity to be optimally adapted to a wide variety of pickup systems. The slim design enables short signal paths to be maintained by placing it in the immediate vicinity of the turntable.
Technical specifications
Reinforcement
36 - 60 dB adjustable in 16 steps
Input resistance
From 25 ohms to 1800 ohms in 31 steps; 47 kOhm
capacity
Basic capacitance = 60 - 100 pF
Connectable capacitance = 47 pF, 100 pF, 147 pF
Entrance
1 x cinch
Exit
1 x cinch
S / N ratio
- 72 dB at 60 dB gain and -94 dB at 36 dB gain
Frequency response
+/- 0.2 dB RIAA equalized
Total harmonic distortion THD + N
0.06%
Crosstalk attenuation
- 96.2 dBA at 10 KHz
Power consumption
7 - 16 VA depending on the charge level of the battery
Dimensions (H x W x D)
58.5 x 200 x 320 mm
Weight
7.7 kg
Warranty period
3 years
| Color: | black - textured paint black |
|---|---|
| Condition: | Brand new |
| Device depth mm: | 320 |
| Device height mm: | 58.5 |
| Device width mm: | 200 |
| Inputs: | Analog RCA |
| Outputs: | Analog RCA |
| Product type: | phono preamp |
| Series: | ADVANCE III |
Safety Information
Product-specific safety instructions can be found in the operating manual.
