Ortofon 2M BLACK Tone pickup
€539.00
% €599.00 RRP (10.02% saved)per Piece incl. VAT / incl. Shipping
Available, delivery time: 1-3 days
GermanyWe ship your goods quickly and safely with DHL. After shipping you will receive a tracking number for package tracking.
Technical specifications
Pickup type | MM (moving magnet) |
Output voltage | 5mV |
Amplifier connection | Phono MM |
Channel deviation at 1kHz | 1dB |
Crosstalk attenuation at 1kHz | 26dB |
Crosstalk attenuation at 15kHz | 15dB |
Frequency range | 20-31,000Hz |
Frequency response | 20-20,000Hz + 2 / -0dB |
Sampling capability at 315Hz | 80 micro-m |
Compliance | 22 micro-m / mN |
Recommended tonearm type | Light and medium difficulty |
Scanning diamond | Shibata, naked |
Waste | r / R 6/50 micro-m |
Tracking force range | 14-17mN (1.4-1.7g) |
Recommended tracking force | 15mN (1.5g) |
Scanning angle | 20 degrees |
DC resistance | 1.2kOhm |
Inductance | 630mH |
Recommended terminating resistor | 47kOhm |
Recommended final capacity | 150-300pF |
Housing material | Noryl |
Weight | 7.2g |
Replacement needle slot | Stylus 2M Black |
Specialty | Winding made of silver-plated OFC copper wire |
| Condition: | New goods |
|---|---|
| Configuration: | Universal |
| Product type: | Pickup MM |
