Dynavector DV-20X2A MC cartridge

Discover the DV 20X2A phono cartridge

The DV 20X2A phono cartridge is a high-quality model from the Dynavector MC series that will delight both sound enthusiasts and newcomers to the field of moving coil (MC) cartridges. This cartridge combines the basic construction of the higher-quality Dynavector models XX-2A and Te Kaitora Rua with a solid aluminum housing, a stable aluminum cantilever and a micro-ridge stylus tip. With its versatile features, the DV 20X2A is an ideal choice for anyone who wants to enjoy the full sound spectrum of an MC cartridge without having to rely on a complex setup.

Two versions for different systems

The DV 20X2A phono cartridge is available in two versions: 20X2A-L (low output model) and 20X2A-H (high output model). Depending on the requirements of your audio system, you can choose between these two variants:

20X2A-H (High Output Model): This model achieves an output voltage of 2.8 mV thanks to Dynavector's advanced winding technology. By using ultra-fine wire that is wound several times, this cartridge can produce a high output voltage comparable to that of a moving magnet (MM) cartridge. This allows the MC cartridge to be connected directly to a PHONO input for MM without the need for an additional preamplifier or transformer.

20X2A-L (Low Output Model): This model offers an output voltage of 0.3 mV and uses the same PCOCC wires as the higher-end models for the coil winding. The recommended preamplifier load resistance is 30O or more, ensuring compatibility with most preamplifiers and MC transformers.

Optimized magnetics for maximum sound enjoyment

A standout feature of the DV 20X2A phono cartridge is the specially treated magnetic circuit. This core of an MC cartridge is made of pure iron, which is known for its stable magnetic properties and minimal distortion. A special annealing process that optimizes magnetization achieves a resonance capability that enables unparalleled sound quality and resolution. Careful control of temperature, environment, heating time, and heating and cooling rates ensures that the sound remains free of distortion while remaining lively and dynamic.

Perfect adaptation to different tonearms

With a compliance of 12mm/N and a weight of 9.2g, the DV 20X2A series is compatible with most light to medium weight tonearms. It is recommended to use lightweight headshells for best performance. This flexibility makes the cartridge ideal for a wide range of turntables and allows for easy integration into existing audio equipment.

Use of neodymium and soft magnets

The DV 20X2A phono cartridge uses a patented technology with neodymium and soft magnets. This combination minimizes distortion and unpleasant, sharp sound peaks that can be caused by rare earth magnets. At the same time, a clear and clean sound separation is achieved, which greatly increases the listening pleasure.

High-quality aluminum cantilever and micro-ridge needle

Another highlight of the DV 20X2A is the hollow cantilever made of hard aluminum. This reduces the mass of the vibration system and enables a wide frequency bandwidth with clear highs. The Micro-Ridge needle tip, which has a minimal radius curvature of only 2 micrometers, offers exceptional durability and remains resistant to wear even after intensive use. This design ensures precise tracking of the record grooves and contributes to impressive sound quality.

Combining innovative technology with high-quality construction, this cartridge offers an unparalleled listening experience. Whether you are an experienced audiophile or a newbie to vinyl records, the DV 20X2A phono cartridge is the perfect choice for you.

Technical data of the DV 20X2A

Type:
High/Low Output Moving Coil Cartridge with Flux Damper and Soft Magnetics

Output voltage:
2.8 mV (High Output) / 0.3 mV (Low Output) at 1KHz, 5cm/sec.

Channel separation:
25 dB at 1KHz

Channel balance:
1.0dB at 1KHz

Frequency response:
20 - 20,000 Hz (±2 dB)

Compliance:
12mm/N

Tracking force:
1.8 - 2.2g

Impedance:
150 ohms (high output) / 5 ohms (low output)

Recommended load impedance:
1,000 ohms (high output) / > 30 ohms (low output)

Cantilevers:
6 mm length, hard aluminum tube

Needle tip:
Micro-Ridge, Naked Diamond

Weight:
9.2g
