Acoustic Signature Tornado Neo + TA 2000 Neo 9 Zoll with MCX4
€13,680.00
per Piece incl. VAT / incl. Shipping
- After placing your order, your Account Manager will contact you to schedule delivery and installation.
- We deliver your new devices in Germany and Austria personally to the place of installation - no courier, no forwarding agency.
- The Auditorium Team installs your new devices professionally and connects them to existing components.
With this perfectly matched analog bundle, Acoustic Signature presents an uncompromising solution for discerning vinyl enthusiasts. The interplay of the Tornado NEO turntable, the TA-2000 NEO tonearm, and the MCX4 moving-coil cartridge combines innovative engineering, robust construction, and the finest tracking precision into a sonically outstanding package.
DRIVE – TORNADO NEO
The Tornado NEO was developed as a particularly flexible mass-loaded turntable in the NEO line. It is already prepared for up to three tonearms and combines exceptional smoothness with enormous sonic authority.
The fully insulated AC motor operates with the external digital motor controller DMC-20, including AVC technology Level 1 (Automatic Vibration Control). The ultra-precise DTD bearing with diamond-coated spindle ensures maximum stability with minimal friction.
Four integrated silencer modules selectively reduce platter resonances, while the solid aluminum housing with CLD technology ensures excellent resonance behavior. The result is a powerful, controlled, and high-resolution sound reproduction with impressive quietness and dynamics.
TONEARM – TA-2000 NEO
The TA-2000 NEO guides the cartridge through the groove with the utmost precision. Its rigid, low-resonance carbon dual-layer tonearm tube, in conjunction with a precision gimbal ball bearing, ensures virtually frictionless and backlash-free movement.
The high-quality internal wiring and the included phono cable guarantee low-loss signal transmission. Extensive adjustment options such as VTA, azimuth, and anti-skating allow for precise adaptation to different cartridges.
Available in 9-inch or 12-inch versions and mountable according to SME or Rega standards, the TA-2000 NEO can be flexibly integrated into a wide variety of high-end setups.
MCX4
The MCX4 is the reference model of the MCX series and represents the sonic pinnacle of this bundle. Its Nude Shibata stylus ensures the highest detail resolution and precise groove tracking.
Gold-plated coils made of oxygen-free copper enable exceptionally precise signal transmission. The CNC-machined, resonance-optimized aluminum housing minimizes vibrations and supports exceptionally transparent, dynamic, and musical sound reproduction.
With its compliance, the MCX4 is ideally suited for medium to heavy tonearms such as the TA-2000 NEO.
TECHNICAL DATA
TORNADO NEO DRIVE
- AC motors: 1
- Drive: Speed-controlled belt drive with fine speed adjustment for sub-platter
- AVC: Level 1
- Speed range: 33 1/3 RPM and 45 RPM
- Power supply: External digital motor controller DMC-20 with multi-voltage power supply (100 – 260 V AC, 50 / 60 Hz)
- Control panel: External, flexibly positionable
- Bearings: Dura Turn Diamond bearings
- Tonearm base: Adjustable armboards, 1 fitted, 2 optionally mountable
- Tonearm compatibility: 9- to 12-inch tonearms
- Maximum number of tonearms: 3
- Turntable: Anodized aluminum, Ø 310 x 50 mm, 11 kg, with 4 silencer modules
- Chassis: 45 mm thick aluminum alloy
- Stand feet: Height-adjustable, yellow-damped aluminum feet
- Dimensions (W x D x H): 450 x 460 x 160 mm
- Weight: 26.5 kg
TA-2000 NEO tonearm
- Available sizes: 9-inch version, 12-inch version
- Length: 293 mm (9 inches), 358 mm (12 inches)
- Effective length: 239.3 mm (9 inches), 309 mm (12 inches)
- Installation distance: 222 mm (9 inches), 295.8 mm (12 inches)
- Total weight: 545 g (9 inch), 547 g (12 inch)
- Effective mass: 9.6 g (9 inch), 12.6 g (12 inch)
- Offset angle: 23.9° (9 inches), 12.1° (12 inches)
- Overhang: 17.3 mm (9 inches), 13.2 mm (12 inches)
- Recommended cartridge weight: 6 – 16 g
- Mounting: SME or Rega standard
- Arm tube: Carbon dual-layer
- Internal wiring: Studio-quality copper
- Phono cable: 1.5 m
- Connections: 5-pin panel mount connector, RCA connector, ground connection
MCX4 sound pickup
- System: Moving Coil
- Needle cut: Nude-Shibata
- Coil material: Gold-plated OFC copper
- Housing: Resonance-optimized aluminum
- Output voltage (1 kHz, 5 cm/s): 0.3 mV
- Channel balance (1 kHz): < 1.0 dB
- Channel separation (1 kHz): > 26 dB
- Compliance: 15 m/mN
- Tracking force range: 2.1 – 2.5 g
- Recommended tracking force: 2.3 g
- Frequency range (-3 dB): 20 – 25,000 Hz
- Frequency response (20 – 20,000 Hz): ± 1.5 dB
- Coil impedance: 5 ohms
- Recommended termination impedance: 100 ohms
- Weight: 12.6 g
| Cartridge type: | MC |
|---|---|
| Color: | silver |
| Condition: | new item |
| Device depth mm: | 460 |
| Device height mm: | 160 |
| Device width mm: | 450 |
| Drive: | belt drive |
| Dust cover included: | No |
| Fully assembled / ready to play: | No |
| Playback speeds: | 33, 45 |
| Product type: | turntable |
Manufacturer
AS-Distribution GmbH
Hillenbrand Straße 10
73079 Süßen
Deutschland
+49 7162 207 97 0
info@as-distribution.de
www.acoustic-signature.de
Safety Information
Product-specific safety instructions can be found in the operating manual.
